Woonyoung WYPA2 General Type SPD, Single-Phase Earthed 1P2W, 10-70kA, 220-440VAC

Woonyoung WYPA2 General Type SPD, Single-Phase Earthed 1P2W, 10-70kA, 220-440VAC

Block-type surge protective device for single-phase earthed AC systems that diverts surges from line and neutral to earth.

Key features

  • For 220, 380 and 440VAC single-phase earthed systems
  • Maximum discharge current 10kA to 70kA
  • Voltage protection level below 1.5kV
  • Screw terminal block housing

Specifications

Connection Screw terminal
Terminal lug size Type A: max 8 / min 3.5 mm; Type B: max 13 / min 5 mm
WYPA2010T220 Nominal voltage: AC220V | Max. continuous voltage Uc: AC300V | Max. discharge current Imax: 10kA | Nominal discharge current In: 5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.1 kg
WYPA2010T380 Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 10kA | Nominal discharge current In: 5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.1 kg
WYPA2010T440 Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 10kA | Nominal discharge current In: 5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.1 kg
WYPA2015T220 Nominal voltage: AC220V | Max. continuous voltage Uc: AC275V | Max. discharge current Imax: 15kA | Nominal discharge current In: 7.5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.2 kg
WYPA2015T380 Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 15kA | Nominal discharge current In: 7.5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.2 kg
WYPA2015T440 Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 15kA | Nominal discharge current In: 7.5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.2 kg
WYPA2025T220 Nominal voltage: AC220V | Max. continuous voltage Uc: AC275V | Max. discharge current Imax: 25kA | Nominal discharge current In: 12.5kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.3 kg
WYPA2025T380 Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 25kA | Nominal discharge current In: 12.5kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.3 kg
WYPA2025T440 Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 25kA | Nominal discharge current In: 12.5kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.3 kg
WYPA2040T220 Nominal voltage: AC220V | Max. continuous voltage Uc: AC275V | Max. discharge current Imax: 40kA | Nominal discharge current In: 20kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.4 kg
WYPA2040T380 Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 40kA | Nominal discharge current In: 20kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.4 kg
WYPA2040T440 Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 40kA | Nominal discharge current In: 20kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.4 kg
WYPA2070T220 Nominal voltage: AC220V | Max. continuous voltage Uc: AC320V | Max. discharge current Imax: 70kA | Nominal discharge current In: 35kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.5 kg
WYPA2070T380 Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 70kA | Nominal discharge current In: 35kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.5 kg
WYPA2070T440 Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 70kA | Nominal discharge current In: 35kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.5 kg
Surge Protection DevicesWoonyoung
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung WYPA2 General Type SPD, Single-Phase Earthed 1P2W, 10-70kA, 220-440VAC

Brand Woonyoung·Surge Protection Devices

Available part numbers (15)

WYPA2010T220, WYPA2010T380, WYPA2010T440, WYPA2015T220, WYPA2015T380, WYPA2015T440, WYPA2025T220, WYPA2025T380, WYPA2025T440, WYPA2040T220 + 5 more — see full table ↓

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WYPA2010T220Nominal voltage: AC220V | Max. continuous voltage Uc: AC300V | Max. discharge current Imax: 10kA | Nominal discharge current In: 5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.1 kg
WYPA2010T380Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 10kA | Nominal discharge current In: 5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.1 kg
WYPA2010T440Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 10kA | Nominal discharge current In: 5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.1 kg
WYPA2015T220Nominal voltage: AC220V | Max. continuous voltage Uc: AC275V | Max. discharge current Imax: 15kA | Nominal discharge current In: 7.5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.2 kg
WYPA2015T380Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 15kA | Nominal discharge current In: 7.5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.2 kg
WYPA2015T440Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 15kA | Nominal discharge current In: 7.5kA | Voltage protection level Up: < 1.5kV | Dimension type: A | Weight: 0.2 kg
WYPA2025T220Nominal voltage: AC220V | Max. continuous voltage Uc: AC275V | Max. discharge current Imax: 25kA | Nominal discharge current In: 12.5kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.3 kg
WYPA2025T380Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 25kA | Nominal discharge current In: 12.5kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.3 kg
WYPA2025T440Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 25kA | Nominal discharge current In: 12.5kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.3 kg
WYPA2040T220Nominal voltage: AC220V | Max. continuous voltage Uc: AC275V | Max. discharge current Imax: 40kA | Nominal discharge current In: 20kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.4 kg
WYPA2040T380Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 40kA | Nominal discharge current In: 20kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.4 kg
WYPA2040T440Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 40kA | Nominal discharge current In: 20kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.4 kg
WYPA2070T220Nominal voltage: AC220V | Max. continuous voltage Uc: AC320V | Max. discharge current Imax: 70kA | Nominal discharge current In: 35kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.5 kg
WYPA2070T380Nominal voltage: AC380V | Max. continuous voltage Uc: AC510V | Max. discharge current Imax: 70kA | Nominal discharge current In: 35kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.5 kg
WYPA2070T440Nominal voltage: AC440V | Max. continuous voltage Uc: AC625V | Max. discharge current Imax: 70kA | Nominal discharge current In: 35kA | Voltage protection level Up: < 1.5kV | Dimension type: B | Weight: 0.5 kg
