YASKAWA MECHATROLINK-II Distributed I/O Modules & Repeater

YASKAWA MECHATROLINK-II Distributed I/O Modules & Repeater

MECHATROLINK-II slave I/O modules and repeater for distributed digital, analog and pulse signals on MP-series and MA100 controller networks.

Key features

  • IO2310/IO2330: 64 inputs and 64 outputs, sinking or sourcing output
  • PL2900 reversible counter and PL2910 pulse output modules
  • AN2900 4-ch analog input and AN2910 2-ch analog output (-10 to +10 V)
  • Compact IO2900/IO2910/IO2920 16/8-point modules and IO2950 relay outputs
  • REP2000 repeater extends MECHATROLINK-II up to 100 m total (24 VDC)
  • IO2310/IO2330 and JAMSC-IO29xx also usable as MA100 slaves

Specifications

Brand YASKAWA
Category Distributed (network) module
Network MECHATROLINK-II
Compatible MP3000 / MP2000 series, MA100
Standards UL certified; EU Directives, KC Mark
Source YASKAWA MP2000 Series Catalog, p. 53-54, 77; MP3000 Series Catalog, p. 67, 70, 86, 91
JEPMC-IO2310-E Model name: IO2310 | Function: 64 in / 64 out (sink)
JEPMC-IO2330-E Model name: IO2330 | Function: 64 in / 64 out (source)
JEPMC-PL2900-E Model name: PL2900 | Function: Reversible counter, 2 ch
JEPMC-PL2910-E Model name: PL2910 | Function: Pulse output, 2 ch
JEPMC-AN2900-E Model name: AN2900 | Function: Analog input -10 to +10 V, 4 ch
JEPMC-AN2910-E Model name: AN2910 | Function: Analog output -10 to +10 V, 2 ch
JAMSC-IO2900-E Model name: IO2900 | Function: 16 inputs
JAMSC-IO2910-E Model name: IO2910 | Function: 16 outputs (sink)
JAMSC-IO2920-E Model name: IO2920 | Function: 8 in / 8 out (sink)
JAMSC-IO2950-E Model name: IO2950 | Function: 8 relay contact outputs
JEPMC-REP2000-E Model name: REP2000 | Function: MECHATROLINK-II repeater
Machine Controller ModulesYASKAWA
11 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA MECHATROLINK-II Distributed I/O Modules & Repeater

Brand YASKAWA·Machine Controller Modules

Available part numbers (11)

JEPMC-IO2310-E, JEPMC-IO2330-E, JEPMC-PL2900-E, JEPMC-PL2910-E, JEPMC-AN2900-E, JEPMC-AN2910-E, JAMSC-IO2900-E, JAMSC-IO2910-E, JAMSC-IO2920-E, JAMSC-IO2950-E + 1 more — see full table ↓

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JEPMC-IO2310-EModel name: IO2310 | Function: 64 in / 64 out (sink)
JEPMC-IO2330-EModel name: IO2330 | Function: 64 in / 64 out (source)
JEPMC-PL2900-EModel name: PL2900 | Function: Reversible counter, 2 ch
JEPMC-PL2910-EModel name: PL2910 | Function: Pulse output, 2 ch
JEPMC-AN2900-EModel name: AN2900 | Function: Analog input -10 to +10 V, 4 ch
JEPMC-AN2910-EModel name: AN2910 | Function: Analog output -10 to +10 V, 2 ch
JAMSC-IO2900-EModel name: IO2900 | Function: 16 inputs
JAMSC-IO2910-EModel name: IO2910 | Function: 16 outputs (sink)
JAMSC-IO2920-EModel name: IO2920 | Function: 8 in / 8 out (sink)
JAMSC-IO2950-EModel name: IO2950 | Function: 8 relay contact outputs
JEPMC-REP2000-EModel name: REP2000 | Function: MECHATROLINK-II repeater
