YASKAWA MP2300 / MP2310 / MP2300S / MP2400 Basic Modules

YASKAWA MP2300 / MP2310 / MP2300S / MP2400 Basic Modules

All-in-one MP2000 series basic modules combining power supply, CPU, MECHATROLINK-II motion network and communication in one compact unit.

Key features

  • 24 VDC input with one MECHATROLINK-II circuit (21 stations, up to 16 servo axes)
  • MP2300: built-in 8 inputs / 4 outputs, 3 optional-module slots
  • MP2310: 100 Mbps Ethernet port and 3 optional-module slots
  • MP2300S: Ethernet, 1 slot; terminator and DIN-rail fixtures supplied
  • MP2400: Ethernet, no option slot, CPU ready relay output
  • Battery JZSP-BA01 for backup data provided

Specifications

Brand YASKAWA
Series MP2000
Controller type Basic module (all-in-one)
Power supply 24 VDC +/-20%
Motion network MECHATROLINK-II
Engineering tool MPE720
Source YASKAWA MP2000 Series Catalog, p. 24, 41, 76
JEPMC-MP2300-E Model name: MP2300 | Ethernet: - | I/O: 8 in / 4 out | Option slots: 3
JEPMC-MP2310-E Model name: MP2310 | Ethernet: 1 port, 100 Mbps | I/O: - | Option slots: 3
JEPMC-MP2300S-E Model name: MP2300S | Ethernet: 1 port, 100 Mbps | I/O: 1 relay output | Option slots: 1
JEPMC-MP2400-E Model name: MP2400 | Ethernet: 1 port, 100 Mbps | I/O: 1 relay output | Option slots: None
Motion ControllersYASKAWA
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA MP2300 / MP2310 / MP2300S / MP2400 Basic Modules

Brand YASKAWA·Motion Controllers

Available part numbers (4)

JEPMC-MP2300-E, JEPMC-MP2310-E, JEPMC-MP2300S-E, JEPMC-MP2400-E

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JEPMC-MP2300-EModel name: MP2300 | Ethernet: - | I/O: 8 in / 4 out | Option slots: 3
JEPMC-MP2310-EModel name: MP2310 | Ethernet: 1 port, 100 Mbps | I/O: - | Option slots: 3
JEPMC-MP2300S-EModel name: MP2300S | Ethernet: 1 port, 100 Mbps | I/O: 1 relay output | Option slots: 1
JEPMC-MP2400-EModel name: MP2400 | Ethernet: 1 port, 100 Mbps | I/O: 1 relay output | Option slots: None
