YASKAWA MP3000/MP2000 Rack I/O Modules (LIO/DI/DO/AI/AO/CNTR)

YASKAWA MP3000/MP2000 Rack I/O Modules (LIO/DI/DO/AI/AO/CNTR)

Optional digital, analog and counter I/O modules that mount in the option slots of MP3000 and MP2000 machine controllers.

Key features

  • LIO-01/-02: 16 inputs, 16 outputs and 1 pulse input (sink or source)
  • LIO-04/-05: 32 inputs and 32 outputs (sink or source)
  • LIO-06 mixed module: 8 DI, 8 DO, 1 analog in, 1 analog out, 1 counter
  • DI-01 64-point input and DO-01 64-point sinking output modules
  • AI-01 8-ch analog input, AO-01 4-ch analog output, CNTR-01 2-ch counter
  • DI-01 requires CPU module Ver.1.47+ and MPE720 Ver.7.45+

Specifications

Brand YASKAWA
Category Optional I/O module
Compatible MP3000 / MP2000 series
Mounting Base unit option slot
Standards UL certified; EU Directives, KC Mark
Source YASKAWA MP3000 Series Catalog, p. 61-63, 86, 91; MP2000 Series Catalog, p. 77
JAPMC-IO2300-E Model name: LIO-01 | I/O: 16 in / 16 out (sink), 1 pulse in
JAPMC-IO2301-E Model name: LIO-02 | I/O: 16 in / 16 out (source), 1 pulse in
JAPMC-IO2303-E Model name: LIO-04 | I/O: 32 in / 32 out (sink)
JAPMC-IO2304-E Model name: LIO-05 | I/O: 32 in / 32 out (source)
JAPMC-IO2305-E Model name: LIO-06 | I/O: 8 DI/8 DO, 1 AI, 1 AO, 1 counter
JAPMC-DI2300-E Model name: DI-01 | I/O: 64 inputs
JAPMC-DO2300-E Model name: DO-01 | I/O: 64 outputs (sink)
JAPMC-AN2300-E Model name: AI-01 | I/O: 8 analog input channels
JAPMC-AN2310-E Model name: AO-01 | I/O: 4 analog output channels
JAPMC-PL2300-E Model name: CNTR-01 | I/O: 2 counter ch, 5 V diff. or 12 V
Machine Controller ModulesYASKAWA
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA MP3000/MP2000 Rack I/O Modules (LIO/DI/DO/AI/AO/CNTR)

Brand YASKAWA·Machine Controller Modules

Available part numbers (10)

JAPMC-IO2300-E, JAPMC-IO2301-E, JAPMC-IO2303-E, JAPMC-IO2304-E, JAPMC-IO2305-E, JAPMC-DI2300-E, JAPMC-DO2300-E, JAPMC-AN2300-E, JAPMC-AN2310-E, JAPMC-PL2300-E

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JAPMC-IO2300-EModel name: LIO-01 | I/O: 16 in / 16 out (sink), 1 pulse in
JAPMC-IO2301-EModel name: LIO-02 | I/O: 16 in / 16 out (source), 1 pulse in
JAPMC-IO2303-EModel name: LIO-04 | I/O: 32 in / 32 out (sink)
JAPMC-IO2304-EModel name: LIO-05 | I/O: 32 in / 32 out (source)
JAPMC-IO2305-EModel name: LIO-06 | I/O: 8 DI/8 DO, 1 AI, 1 AO, 1 counter
JAPMC-DI2300-EModel name: DI-01 | I/O: 64 inputs
JAPMC-DO2300-EModel name: DO-01 | I/O: 64 outputs (sink)
JAPMC-AN2300-EModel name: AI-01 | I/O: 8 analog input channels
JAPMC-AN2310-EModel name: AO-01 | I/O: 4 analog output channels
JAPMC-PL2300-EModel name: CNTR-01 | I/O: 2 counter ch, 5 V diff. or 12 V
