YASKAWA MP3300 Machine Controller CPU Modules & Base Units

YASKAWA MP3300 Machine Controller CPU Modules & Base Units

Compact MP3300 machine controller built from CPU-301/CPU-302 modules and MBU-30x base units with integrated power supply.

Key features

  • CPU-301: high-speed scan and communication cycle down to 250 us
  • CPU-302: high-speed scan and communication cycle down to 125 us (occupies 2 slots)
  • 16-axis and 32-axis versions with 15 MB or 31 MB program capacity
  • MECHATROLINK-III (2 ports), Ethernet 10/100 port and USB 2.0 storage port
  • Base units for 100/200 VAC (8 slots) or 24 VDC (8, 3 or 1 slots) input
  • Battery JZSP-BA01 for backup data included with CPU modules

Specifications

Brand YASKAWA
Series MP3000 (MP3300)
Controller type Module (base-mounted)
Motion network MECHATROLINK-III
Engineering tool MPE720 Ver.7
Standards UL certified; EU Directives, KC Mark
Source YASKAWA MP3000 Series Catalog, p. 52, 85, 90; MP3300 Catalog, p. 56
JAPMC-CP3301-1-E Unit: CPU module | Model name: CPU-301 (16 axes) | Scan / cycle: 250 us min. | Program: 15 MB
JAPMC-CP3301-2-E Unit: CPU module | Model name: CPU-301 (32 axes) | Scan / cycle: 250 us min. | Program: 31 MB
JAPMC-CP3302-1-E Unit: CPU module | Model name: CPU-302 (16 axes) | Scan / cycle: 125 us min. | Program: 15 MB
JAPMC-CP3302-2-E Unit: CPU module | Model name: CPU-302 (32 axes) | Scan / cycle: 125 us min. | Program: 31 MB
JEPMC-BU3301-E Unit: Base unit | Model name: MBU-301 | Input: 100/200 VAC | Slots: 8
JEPMC-BU3302-E Unit: Base unit | Model name: MBU-302 | Input: 24 VDC | Slots: 8
JEPMC-BU3303-E Unit: Base unit | Model name: MBU-303 | Input: 24 VDC | Slots: 3
JEPMC-BU3304-E Unit: Base unit | Model name: MBU-304 | Input: 24 VDC | Slots: 1
Motion ControllersYASKAWA
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA MP3300 Machine Controller CPU Modules & Base Units

Brand YASKAWA·Motion Controllers

Available part numbers (8)

JAPMC-CP3301-1-E, JAPMC-CP3301-2-E, JAPMC-CP3302-1-E, JAPMC-CP3302-2-E, JEPMC-BU3301-E, JEPMC-BU3302-E, JEPMC-BU3303-E, JEPMC-BU3304-E
