YASKAWA Sigma-7 SGLF Linear Servo Motor Magnet Tracks (SGLFM/SGLFM2)

YASKAWA Sigma-7 SGLF Linear Servo Motor Magnet Tracks (SGLFM/SGLFM2)

YASKAWA SGLFM2 and SGLFM magnet tracks are the permanent-magnet stators for the core-type SGLFW2 and SGLFW linear servo motor coils.

Key features

  • SGLFM2 tracks for SGLFW2 coils: 270/450/630 mm (30 mm height) and 306/510/714 mm (45/90/135 mm)
  • SGLFM tracks for SGLFW coils: 324/540/756 mm (20/36 mm) and 405/675/945 mm (47.5/95 mm)
  • Tracks can be joined end to end for longer strokes (align reference marks in the same direction)
  • SGLFM available with magnet cover (suffix C)
  • Design revision A

Specifications

Series Sigma-7 linear servo, SGLF
Motor Type Core-type F model, magnet track
Design Revision A
Joining Connectable end to end
Excitation Permanent magnet
Source YASKAWA Sigma-7 Catalog (Korean ed.), p. 209-246
SGLFM2-30270A Model Line: SGLFM2 | Magnet Height: 30 mm | Length: 270 mm | Mass: 0.9 kg | Cover: None | Coil: SGLFW2-30
SGLFM2-30450A Model Line: SGLFM2 | Magnet Height: 30 mm | Length: 450 mm | Mass: 1.5 kg | Cover: None | Coil: SGLFW2-30
SGLFM2-30630A Model Line: SGLFM2 | Magnet Height: 30 mm | Length: 630 mm | Mass: 2.0 kg | Cover: None | Coil: SGLFW2-30
SGLFM2-45306A Model Line: SGLFM2 | Magnet Height: 45 mm | Length: 306 mm | Mass: 1.5 kg | Cover: None | Coil: SGLFW2-45
SGLFM2-45510A Model Line: SGLFM2 | Magnet Height: 45 mm | Length: 510 mm | Mass: 2.5 kg | Cover: None | Coil: SGLFW2-45
SGLFM2-45714A Model Line: SGLFM2 | Magnet Height: 45 mm | Length: 714 mm | Mass: 3.4 kg | Cover: None | Coil: SGLFW2-45
SGLFM2-90306A Model Line: SGLFM2 | Magnet Height: 90 mm | Length: 306 mm | Mass: 2.6 kg | Cover: None | Coil: SGLFW2-90
SGLFM2-90510A Model Line: SGLFM2 | Magnet Height: 90 mm | Length: 510 mm | Mass: 4.2 kg | Cover: None | Coil: SGLFW2-90
SGLFM2-90714A Model Line: SGLFM2 | Magnet Height: 90 mm | Length: 714 mm | Mass: 5.9 kg | Cover: None | Coil: SGLFW2-90
SGLFM2-1D306A Model Line: SGLFM2 | Magnet Height: 135 mm | Length: 306 mm | Mass: 3.7 kg | Cover: None | Coil: SGLFW2-1D
SGLFM2-1D510A Model Line: SGLFM2 | Magnet Height: 135 mm | Length: 510 mm | Mass: 6.2 kg | Cover: None | Coil: SGLFW2-1D
SGLFM2-1D714A Model Line: SGLFM2 | Magnet Height: 135 mm | Length: 714 mm | Mass: 8.6 kg | Cover: None | Coil: SGLFW2-1D
SGLFM-20324A Model Line: SGLFM | Magnet Height: 20 mm | Length: 324 mm | Mass: 0.9 kg | Cover: None | Coil: SGLFW-20
SGLFM-20324AC Model Line: SGLFM | Magnet Height: 20 mm | Length: 324 mm | Mass: 0.9 kg | Cover: Magnet cover | Coil: SGLFW-20
SGLFM-20540A Model Line: SGLFM | Magnet Height: 20 mm | Length: 540 mm | Mass: 1.4 kg | Cover: None | Coil: SGLFW-20
SGLFM-20540AC Model Line: SGLFM | Magnet Height: 20 mm | Length: 540 mm | Mass: 1.4 kg | Cover: Magnet cover | Coil: SGLFW-20
SGLFM-20756A Model Line: SGLFM | Magnet Height: 20 mm | Length: 756 mm | Mass: 2 kg | Cover: None | Coil: SGLFW-20
SGLFM-20756AC Model Line: SGLFM | Magnet Height: 20 mm | Length: 756 mm | Mass: 2 kg | Cover: Magnet cover | Coil: SGLFW-20
SGLFM-35324A Model Line: SGLFM | Magnet Height: 36 mm | Length: 324 mm | Mass: 1.2 kg | Cover: None | Coil: SGLFW-35
SGLFM-35324AC Model Line: SGLFM | Magnet Height: 36 mm | Length: 324 mm | Mass: 1.2 kg | Cover: Magnet cover | Coil: SGLFW-35
SGLFM-35540A Model Line: SGLFM | Magnet Height: 36 mm | Length: 540 mm | Mass: 2 kg | Cover: None | Coil: SGLFW-35
SGLFM-35540AC Model Line: SGLFM | Magnet Height: 36 mm | Length: 540 mm | Mass: 2 kg | Cover: Magnet cover | Coil: SGLFW-35
SGLFM-35756A Model Line: SGLFM | Magnet Height: 36 mm | Length: 756 mm | Mass: 2.9 kg | Cover: None | Coil: SGLFW-35
SGLFM-35756AC Model Line: SGLFM | Magnet Height: 36 mm | Length: 756 mm | Mass: 2.9 kg | Cover: Magnet cover | Coil: SGLFW-35
SGLFM-50405A Model Line: SGLFM | Magnet Height: 47.5 mm | Length: 405 mm | Mass: 2.8 kg | Cover: None | Coil: SGLFW-50
SGLFM-50405AC Model Line: SGLFM | Magnet Height: 47.5 mm | Length: 405 mm | Mass: 2.8 kg | Cover: Magnet cover | Coil: SGLFW-50
SGLFM-50675A Model Line: SGLFM | Magnet Height: 47.5 mm | Length: 675 mm | Mass: 4.6 kg | Cover: None | Coil: SGLFW-50
SGLFM-50675AC Model Line: SGLFM | Magnet Height: 47.5 mm | Length: 675 mm | Mass: 4.6 kg | Cover: Magnet cover | Coil: SGLFW-50
SGLFM-50945A Model Line: SGLFM | Magnet Height: 47.5 mm | Length: 945 mm | Mass: 6.5 kg | Cover: None | Coil: SGLFW-50
SGLFM-50945AC Model Line: SGLFM | Magnet Height: 47.5 mm | Length: 945 mm | Mass: 6.5 kg | Cover: Magnet cover | Coil: SGLFW-50
SGLFM-1Z405A Model Line: SGLFM | Magnet Height: 95 mm | Length: 405 mm | Mass: 5 kg | Cover: None | Coil: SGLFW-1Z
SGLFM-1Z405AC Model Line: SGLFM | Magnet Height: 95 mm | Length: 405 mm | Mass: 5 kg | Cover: Magnet cover | Coil: SGLFW-1Z
SGLFM-1Z675A Model Line: SGLFM | Magnet Height: 95 mm | Length: 675 mm | Mass: 8.3 kg | Cover: None | Coil: SGLFW-1Z
SGLFM-1Z675AC Model Line: SGLFM | Magnet Height: 95 mm | Length: 675 mm | Mass: 8.3 kg | Cover: Magnet cover | Coil: SGLFW-1Z
SGLFM-1Z945A Model Line: SGLFM | Magnet Height: 95 mm | Length: 945 mm | Mass: 12 kg | Cover: None | Coil: SGLFW-1Z
SGLFM-1Z945AC Model Line: SGLFM | Magnet Height: 95 mm | Length: 945 mm | Mass: 12 kg | Cover: Magnet cover | Coil: SGLFW-1Z
