YASKAWA Sigma-7 SGM7J Geared Servo Motors (50-750 W, HDS gear)

YASKAWA Sigma-7 SGM7J Geared Servo Motors (50-750 W, HDS gear)

The YASKAWA SGM7J geared servo motor combines the 50-750 W SGM7J motor with an integrated HDS precision planetary gearhead.

Key features

  • Integrated HDS precision planetary gearhead, backlash 3 arc-min or less
  • Reduction ratios 1/5, 1/11, 1/21, 1/33 (50 W: 1/5, 1/9, 1/21, 1/33)
  • Output: flange output, straight shaft without key, or straight with key and tap
  • 24-bit absolute or incremental serial encoder
  • Without brake or with 24 VDC holding brake
  • Gearhead protection: totally enclosed, self-cooled IP55 (excluding shaft opening)

Specifications

Series Sigma-7 SGM7J with gearhead
Voltage 200 VAC
Motor rated speed 3000 min-1
Gear type HDS precision planetary gear
Backlash 3 arc-min or less
Protection Totally enclosed, self-cooled IP55
Model key SGM7J-[cap]A[enc]AH[ratio][shaft][option]
Source YASKAWA Sigma-7 Catalog (Korean ed.), p. M-23, 14, 18, 28-33
SGM7J-A5A7AH101 Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AH10C Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AH121 Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AH12C Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AH161 Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AH16C Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5A7AH201 Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AH20C Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AH221 Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AH22C Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AH261 Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AH26C Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5A7AHC01 Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AHC0C Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AHC21 Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AHC2C Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AHC61 Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AHC6C Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5A7AH701 Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AH70C Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AH721 Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AH72C Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AH761 Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AH76C Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAH101 Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAH10C Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAH121 Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAH12C Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAH161 Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAH16C Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAH201 Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAH20C Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAH221 Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAH22C Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAH261 Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAH26C Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAHC01 Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAHC0C Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAHC21 Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAHC2C Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAHC61 Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAHC6C Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAH701 Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAH70C Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAH721 Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAH72C Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAH761 Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAH76C Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AH101 Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AH10C Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AH121 Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AH12C Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AH161 Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AH16C Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AHB01 Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AHB0C Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AHB21 Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AHB2C Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AHB61 Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AHB6C Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AHC01 Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AHC0C Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AHC21 Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AHC2C Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AHC61 Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AHC6C Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AH701 Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AH70C Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AH721 Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AH72C Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AH761 Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AH76C Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAH101 Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAH10C Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAH121 Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAH12C Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAH161 Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAH16C Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAHB01 Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAHB0C Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAHB21 Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAHB2C Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAHB61 Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAHB6C Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAHC01 Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAHC0C Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAHC21 Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAHC2C Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAHC61 Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAHC6C Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAH701 Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAH70C Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAH721 Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAH72C Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAH761 Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAH76C Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AH101 Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AH10C Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AH121 Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AH12C Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AH161 Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AH16C Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AHB01 Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AHB0C Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AHB21 Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AHB2C Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AHB61 Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AHB6C Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AHC01 Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AHC0C Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AHC21 Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AHC2C Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AHC61 Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AHC6C Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AH701 Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AH70C Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AH721 Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AH72C Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AH761 Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AH76C Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAH101 Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAH10C Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAH121 Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAH12C Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAH161 Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAH16C Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAHB01 Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAHB0C Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAHB21 Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAHB2C Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAHB61 Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAHB6C Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAHC01 Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAHC0C Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAHC21 Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAHC2C Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAHC61 Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAHC6C Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAH701 Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAH70C Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAH721 Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAH72C Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAH761 Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAH76C Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AH101 Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AH10C Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AH121 Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AH12C Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AH161 Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AH16C Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AHB01 Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AHB0C Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AHB21 Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AHB2C Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AHB61 Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AHB6C Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AHC01 Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AHC0C Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AHC21 Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AHC2C Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AHC61 Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AHC6C Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AH701 Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AH70C Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AH721 Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AH72C Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AH761 Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AH76C Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAH101 Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAH10C Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAH121 Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAH12C Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAH161 Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAH16C Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAHB01 Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAHB0C Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAHB21 Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAHB2C Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAHB61 Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAHB6C Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAHC01 Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAHC0C Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAHC21 Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAHC2C Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAHC61 Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAHC6C Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAH701 Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAH70C Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAH721 Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAH72C Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAH761 Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAH76C Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AH101 Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AH10C Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AH121 Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AH12C Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AH161 Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AH16C Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AHB01 Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AHB0C Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AHB21 Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AHB2C Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AHB61 Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AHB6C Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AHC01 Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AHC0C Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AHC21 Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AHC2C Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AHC61 Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AHC6C Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AH701 Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AH70C Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AH721 Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AH72C Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AH761 Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AH76C Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAH101 Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAH10C Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAH121 Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAH12C Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAH161 Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAH16C Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAHB01 Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAHB0C Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAHB21 Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAHB2C Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAHB61 Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAHB6C Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAHC01 Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAHC0C Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAHC21 Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAHC2C Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAHC61 Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAHC6C Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAH701 Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAH70C Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAH721 Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAH72C Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAH761 Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAH76C Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AH101 Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AH10C Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AH121 Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AH12C Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AH161 Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AH16C Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AHB01 Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AHB0C Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AHB21 Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AHB2C Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AHB61 Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AHB6C Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AHC01 Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AHC0C Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AHC21 Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AHC2C Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AHC61 Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AHC6C Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AH701 Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AH70C Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AH721 Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AH72C Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AH761 Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AH76C Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAH101 Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAH10C Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAH121 Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAH12C Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAH161 Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAH16C Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAHB01 Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAHB0C Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAHB21 Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAHB2C Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAHB61 Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAHB6C Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAHC01 Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAHC0C Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAHC21 Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAHC2C Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAHC61 Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAHC6C Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAH701 Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAH70C Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAH721 Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAH72C Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAH761 Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAH76C Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AH101 Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AH10C Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AH121 Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AH12C Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AH161 Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AH16C Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AHB01 Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AHB0C Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AHB21 Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AHB2C Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AHB61 Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AHB6C Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AHC01 Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AHC0C Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AHC21 Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AHC2C Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AHC61 Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AHC6C Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AH701 Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AH70C Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AH721 Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AH72C Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AH761 Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AH76C Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAH101 Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAH10C Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAH121 Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAH12C Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAH161 Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAH16C Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAHB01 Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAHB0C Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAHB21 Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAHB2C Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAHB61 Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAHB6C Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAHC01 Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAHC0C Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAHC21 Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAHC2C Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAHC61 Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAHC6C Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAH701 Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAH70C Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAH721 Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAH72C Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAH761 Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAH76C Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
Servo MotorsYASKAWA
336 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA Sigma-7 SGM7J Geared Servo Motors (50-750 W, HDS gear)

Brand YASKAWA·Servo Motors

Available part numbers (336)

SGM7J-A5A7AH101, SGM7J-A5A7AH10C, SGM7J-A5A7AH121, SGM7J-A5A7AH12C, SGM7J-A5A7AH161, SGM7J-A5A7AH16C, SGM7J-A5A7AH201, SGM7J-A5A7AH20C, SGM7J-A5A7AH221, SGM7J-A5A7AH22C + 326 more — see full table ↓

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SGM7J-A5A7AH101Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AH10CMotor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AH121Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AH12CMotor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AH161Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AH16CMotor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5A7AH201Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AH20CMotor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AH221Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AH22CMotor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AH261Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AH26CMotor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5A7AHC01Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AHC0CMotor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AHC21Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AHC2CMotor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AHC61Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AHC6CMotor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5A7AH701Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-A5A7AH70CMotor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5A7AH721Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-A5A7AH72CMotor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5A7AH761Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-A5A7AH76CMotor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAH101Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAH10CMotor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAH121Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAH12CMotor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAH161Motor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAH16CMotor output: 50 W | Ratio: 1/5 | Gear output: 0.433/64 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAH201Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAH20CMotor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAH221Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAH22CMotor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAH261Motor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAH26CMotor output: 50 W | Ratio: 1/9 | Gear output: 1.12/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAHC01Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAHC0CMotor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAHC21Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAHC2CMotor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAHC61Motor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAHC6CMotor output: 50 W | Ratio: 1/21 | Gear output: 2.84/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-A5AFAH701Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-A5AFAH70CMotor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-A5AFAH721Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-A5AFAH72CMotor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-A5AFAH761Motor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-A5AFAH76CMotor output: 50 W | Ratio: 1/33 | Gear output: 3.68/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AH101Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AH10CMotor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AH121Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AH12CMotor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AH161Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AH16CMotor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AHB01Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AHB0CMotor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AHB21Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AHB2CMotor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AHB61Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AHB6CMotor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AHC01Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AHC0CMotor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AHC21Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AHC2CMotor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AHC61Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AHC6CMotor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01A7AH701Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-01A7AH70CMotor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01A7AH721Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-01A7AH72CMotor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01A7AH761Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-01A7AH76CMotor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAH101Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAH10CMotor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAH121Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAH12CMotor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAH161Motor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAH16CMotor output: 100 W | Ratio: 1/5 | Gear output: 1.06/78 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAHB01Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAHB0CMotor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAHB21Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAHB2CMotor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAHB61Motor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAHB6CMotor output: 100 W | Ratio: 1/11 | Gear output: 2.52/72 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAHC01Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAHC0CMotor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAHC21Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAHC2CMotor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAHC61Motor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAHC6CMotor output: 100 W | Ratio: 1/21 | Gear output: 5.35/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-01AFAH701Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-01AFAH70CMotor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-01AFAH721Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-01AFAH72CMotor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-01AFAH761Motor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-01AFAH76CMotor output: 100 W | Ratio: 1/33 | Gear output: 7.35/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AH101Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AH10CMotor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AH121Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AH12CMotor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AH161Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AH16CMotor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AHB01Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AHB0CMotor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AHB21Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AHB2CMotor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AHB61Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AHB6CMotor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AHC01Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AHC0CMotor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AHC21Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AHC2CMotor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AHC61Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AHC6CMotor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2A7AH701Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-C2A7AH70CMotor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2A7AH721Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-C2A7AH72CMotor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2A7AH761Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-C2A7AH76CMotor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAH101Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAH10CMotor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAH121Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAH12CMotor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAH161Motor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAH16CMotor output: 150 W | Ratio: 1/5 | Gear output: 1.68/83 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAHB01Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAHB0CMotor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAHB21Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAHB2CMotor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAHB61Motor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAHB6CMotor output: 150 W | Ratio: 1/11 | Gear output: 3.53/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAHC01Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAHC0CMotor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAHC21Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAHC2CMotor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAHC61Motor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAHC6CMotor output: 150 W | Ratio: 1/21 | Gear output: 6.30/70 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-C2AFAH701Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-C2AFAH70CMotor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-C2AFAH721Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-C2AFAH72CMotor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-C2AFAH761Motor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-C2AFAH76CMotor output: 150 W | Ratio: 1/33 | Gear output: 11.2/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AH101Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AH10CMotor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AH121Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AH12CMotor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AH161Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AH16CMotor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AHB01Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AHB0CMotor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AHB21Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AHB2CMotor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AHB61Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AHB6CMotor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AHC01Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AHC0CMotor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AHC21Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AHC2CMotor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AHC61Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AHC6CMotor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02A7AH701Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-02A7AH70CMotor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02A7AH721Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-02A7AH72CMotor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02A7AH761Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-02A7AH76CMotor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAH101Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAH10CMotor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAH121Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAH12CMotor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAH161Motor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAH16CMotor output: 200 W | Ratio: 1/5 | Gear output: 2.39/75 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAHB01Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAHB0CMotor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAHB21Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAHB2CMotor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAHB61Motor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAHB6CMotor output: 200 W | Ratio: 1/11 | Gear output: 5.74/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAHC01Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAHC0CMotor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAHC21Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAHC2CMotor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAHC61Motor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAHC6CMotor output: 200 W | Ratio: 1/21 | Gear output: 10.2/76 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-02AFAH701Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-02AFAH70CMotor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-02AFAH721Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-02AFAH72CMotor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-02AFAH761Motor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-02AFAH76CMotor output: 200 W | Ratio: 1/33 | Gear output: 17.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AH101Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AH10CMotor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AH121Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AH12CMotor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AH161Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AH16CMotor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AHB01Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AHB0CMotor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AHB21Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AHB2CMotor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AHB61Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AHB6CMotor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AHC01Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AHC0CMotor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AHC21Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AHC2CMotor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AHC61Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AHC6CMotor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04A7AH701Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-04A7AH70CMotor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04A7AH721Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-04A7AH72CMotor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04A7AH761Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-04A7AH76CMotor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAH101Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAH10CMotor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAH121Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAH12CMotor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAH161Motor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAH16CMotor output: 400 W | Ratio: 1/5 | Gear output: 5.35/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAHB01Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAHB0CMotor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAHB21Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAHB2CMotor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAHB61Motor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAHB6CMotor output: 400 W | Ratio: 1/11 | Gear output: 11.5/82 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAHC01Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAHC0CMotor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAHC21Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAHC2CMotor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAHC61Motor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAHC6CMotor output: 400 W | Ratio: 1/21 | Gear output: 23.0/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-04AFAH701Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-04AFAH70CMotor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-04AFAH721Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-04AFAH72CMotor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-04AFAH761Motor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-04AFAH76CMotor output: 400 W | Ratio: 1/33 | Gear output: 34.0/81 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AH101Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AH10CMotor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AH121Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AH12CMotor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AH161Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AH16CMotor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AHB01Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AHB0CMotor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AHB21Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AHB2CMotor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AHB61Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AHB6CMotor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AHC01Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AHC0CMotor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AHC21Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AHC2CMotor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AHC61Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AHC6CMotor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06A7AH701Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-06A7AH70CMotor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06A7AH721Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-06A7AH72CMotor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06A7AH761Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-06A7AH76CMotor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAH101Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAH10CMotor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAH121Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAH12CMotor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAH161Motor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAH16CMotor output: 600 W | Ratio: 1/5 | Gear output: 7.54/79 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAHB01Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAHB0CMotor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAHB21Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAHB2CMotor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAHB61Motor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAHB6CMotor output: 600 W | Ratio: 1/11 | Gear output: 18.1/86 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAHC01Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAHC0CMotor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAHC21Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAHC2CMotor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAHC61Motor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAHC6CMotor output: 600 W | Ratio: 1/21 | Gear output: 32.1/80 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-06AFAH701Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-06AFAH70CMotor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-06AFAH721Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-06AFAH72CMotor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-06AFAH761Motor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-06AFAH76CMotor output: 600 W | Ratio: 1/33 | Gear output: 53.6/85 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AH101Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AH10CMotor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AH121Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AH12CMotor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AH161Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AH16CMotor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AHB01Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AHB0CMotor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AHB21Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AHB2CMotor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AHB61Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AHB6CMotor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AHC01Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AHC0CMotor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AHC21Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AHC2CMotor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AHC61Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AHC6CMotor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08A7AH701Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: None
SGM7J-08A7AH70CMotor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08A7AH721Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: None
SGM7J-08A7AH72CMotor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08A7AH761Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: None
SGM7J-08A7AH76CMotor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit absolute | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAH101Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAH10CMotor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAH121Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAH12CMotor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAH161Motor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAH16CMotor output: 750 W | Ratio: 1/5 | Gear output: 10.0/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAHB01Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAHB0CMotor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAHB21Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAHB2CMotor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAHB61Motor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAHB6CMotor output: 750 W | Ratio: 1/11 | Gear output: 23.1/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAHC01Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAHC0CMotor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAHC21Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAHC2CMotor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAHC61Motor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAHC6CMotor output: 750 W | Ratio: 1/21 | Gear output: 42.1/84 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake
SGM7J-08AFAH701Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: None
SGM7J-08AFAH70CMotor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Flange output | Brake: 24 VDC holding brake
SGM7J-08AFAH721Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: None
SGM7J-08AFAH72CMotor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, no key | Brake: 24 VDC holding brake
SGM7J-08AFAH761Motor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: None
SGM7J-08AFAH76CMotor output: 750 W | Ratio: 1/33 | Gear output: 69.3/88 N·m/% (rated/eff.) | Encoder: 24-bit incremental | Shaft: Straight, key and tap | Brake: 24 VDC holding brake

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Inverters & Drives →
