YASKAWA Sigma-7C Two-Axis SERVOPACKs with Built-in Controller

YASKAWA Sigma-7C Two-Axis SERVOPACKs with Built-in Controller

Sigma-7C two-axis SERVOPACKs combine an MP3300-class machine controller and a two-axis servo drive in one unit for compact, modular machine systems.

Key features

  • Two internal servo axes plus up to four external axes over built-in MECHATROLINK-III (6 controlled axes max.)
  • Controller function module: Ethernet 100 Mbps, USB storage port, 16 inputs / 16 outputs / 1 pulse input; no battery required
  • Saves 34 mm width versus MP3300 one-slot base unit plus 400 W two-axis SERVOPACK; no inter-unit MECHATROLINK cable
  • Option Unit accepts one MP2000-series optional module (except SVA-01, SVB-01, SVC-01, PO-01, MPU-01, 215AIF-01, EXIOIF)
  • Servo response frequency 3.1 kHz; HWBB (STO) safety function optional; engineering with MPE720 Ver.7 and SigmaWin+

Specifications

Series Sigma-7C SERVOPACK with controller
Axes 2 internal + 4 external
Interface Bus connection with references (MA)
Main circuit Three-phase 200 VAC
Servo I/O 12 inputs, 7 outputs
Program memory 15 Mbytes flash
Scan time H 0.5-32 ms, L 2-200 ms
Model key SGD7C-[cap]A MA A
Source YASKAWA Sigma-7C brochure, p. 1-4
SGD7C-1R6AMAA Motor: 0.2 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 100 x 168 x 180 mm
SGD7C-2R8AMAA Motor: 0.4 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 100 x 168 x 180 mm
SGD7C-5R5AMAA Motor: 0.75 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 135 x 168 x 180 mm
SGD7C-7R6AMAA Motor: 1 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 135 x 168 x 180 mm
Servo Drives (SERVOPACKs)YASKAWA
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA Sigma-7C Two-Axis SERVOPACKs with Built-in Controller

Brand YASKAWA·Servo Drives (SERVOPACKs)

Available part numbers (4)

SGD7C-1R6AMAA, SGD7C-2R8AMAA, SGD7C-5R5AMAA, SGD7C-7R6AMAA

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SGD7C-1R6AMAAMotor: 0.2 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 100 x 168 x 180 mm
SGD7C-2R8AMAAMotor: 0.4 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 100 x 168 x 180 mm
SGD7C-5R5AMAAMotor: 0.75 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 135 x 168 x 180 mm
SGD7C-7R6AMAAMotor: 1 kW/axis | Supply: 3-ph 200 VAC | Dimensions: 135 x 168 x 180 mm

Need a different model, or a part not listed here? Send us your parts list →
