YASKAWA V1000 LNFB Single-Phase Input Noise Filters (200 V, 10-30 A)

YASKAWA V1000 LNFB Single-Phase Input Noise Filters (200 V, 10-30 A)

LNFB simple input-side noise filters for single-phase 200 V V1000 drives, in open (DY) and cased (HY) versions.

Key features

  • Reduces noise entering the supply line from the drive input.
  • Install on the input side only, as close to the drive as possible.
  • DY = without case, HY = with case; select by motor capacity.
  • Two filters in parallel are used for 2.2 kW and 3.7 kW single-phase drives.
  • CE (EMC Directive) compliant filters available separately on inquiry.

Specifications

Brand YASKAWA
Series LNFB
Category Input noise filter
Phases Single-phase
Voltage 200 V class
Compatible drives V1000 (CIMR-V?BA)
Source YASKAWA V1000 Catalog (Korean ed.), p. 38-39
LNFB-2102DY Code No.: FIL000128 | Type: Without case | Rated current: 10 A | Motor: 0.1-0.2 kW | Weight: 0.1 kg
LNFB-2152DY Code No.: FIL000129 | Type: Without case | Rated current: 15 A | Motor: 0.4 kW | Weight: 0.2 kg
LNFB-2202DY Code No.: FIL000130 | Type: Without case | Rated current: 20 A | Motor: 0.75 kW (2 pcs 2.2 kW) | Weight: 0.2 kg
LNFB-2302DY Code No.: FIL000131 | Type: Without case | Rated current: 30 A | Motor: 1.5 kW (2 pcs 3.7 kW) | Weight: 0.3 kg
LNFB-2102HY Code No.: FIL000136 | Type: With case | Rated current: 10 A | Motor: 0.1-0.2 kW | Weight: 0.8 kg
LNFB-2152HY Code No.: FIL000137 | Type: With case | Rated current: 15 A | Motor: 0.4 kW | Weight: 0.8 kg
LNFB-2202HY Code No.: FIL000138 | Type: With case | Rated current: 20 A | Motor: 0.75 kW (2 pcs 2.2 kW) | Weight: 0.9 kg
LNFB-2302HY Code No.: FIL000139 | Type: With case | Rated current: 30 A | Motor: 1.5 kW (2 pcs 3.7 kW) | Weight: 1.1 kg
Noise FiltersYASKAWA
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA V1000 LNFB Single-Phase Input Noise Filters (200 V, 10-30 A)

Brand YASKAWA·Noise Filters

Available part numbers (8)

LNFB-2102DY, LNFB-2152DY, LNFB-2202DY, LNFB-2302DY, LNFB-2102HY, LNFB-2152HY, LNFB-2202HY, LNFB-2302HY
