YASKAWA V1000 PS-V10 24 V Control Power Supply Units and Brackets

YASKAWA V1000 PS-V10 24 V Control Power Supply Units and Brackets

External 24 V DC control power units that keep V1000 control and communication circuits alive while the main power is off.

Key features

  • Supplies the control circuit from an external 24 V DC source (24 V +/-20%, 10 W).
  • Network communication and I/O continue while the drive main power is shut off.
  • PS-V10S ships with the white cable; PS-V10M ships with the black connector cable.
  • Unit adds 34 mm to drive width; parameters cannot be changed from the unit alone.
  • Support brackets EZZ020639A/B/C are required for NEMA Type 1; without them the drive is Open Type.

Specifications

Brand YASKAWA
Category 24 V control power supply option
Compatible drives V1000
Input 24 V DC +/-20%
Power consumption 10 W
Drive model prefix CIMR-VT / CIMR-VA
Source YASKAWA V1000 Catalog (Korean ed.), p. 44
PS-V10S Code No.: 100-038-701 | Item: 24 V control power unit | Drive models: 2A0001-0020, BA0001-0018, 4A0001-0011
PS-V10M Code No.: 100-038-702 | Item: 24 V control power unit | Drive models: 2A0030-0069, 4A0018-0038
EZZ020639A Code No.: 100-039-821 | Item: Support bracket (NEMA1) | Drive models: 2A0001-0004, BA0001-0003, 4A0001-0002
EZZ020639B Code No.: 100-039-822 | Item: Support bracket (NEMA1) | Drive models: 2A0006-0040, BA0006-0018, 4A0004-0031
EZZ020639C Code No.: 100-039-823 | Item: Support bracket (NEMA1) | Drive models: 2A0056-0069, 4A0038
Drive Option CardsYASKAWA
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA V1000 PS-V10 24 V Control Power Supply Units and Brackets

Brand YASKAWA·Drive Option Cards

Available part numbers (5)

PS-V10S, PS-V10M, EZZ020639A, EZZ020639B, EZZ020639C

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PS-V10SCode No.: 100-038-701 | Item: 24 V control power unit | Drive models: 2A0001-0020, BA0001-0018, 4A0001-0011
PS-V10MCode No.: 100-038-702 | Item: 24 V control power unit | Drive models: 2A0030-0069, 4A0018-0038
EZZ020639ACode No.: 100-039-821 | Item: Support bracket (NEMA1) | Drive models: 2A0001-0004, BA0001-0003, 4A0001-0002
EZZ020639BCode No.: 100-039-822 | Item: Support bracket (NEMA1) | Drive models: 2A0006-0040, BA0006-0018, 4A0004-0031
EZZ020639CCode No.: 100-039-823 | Item: Support bracket (NEMA1) | Drive models: 2A0056-0069, 4A0038
