Yuken — 007 Series Throttle & Check Modular Valve (Sandwich Type)

Yuken — 007 Series Throttle & Check Modular Valve (Sandwich Type)

007 Series Modular Valves — Throttle & Check.

Key features

  • Sandwich/stack mounting
  • Detailed specifications by inquiry

Specifications

Series 007 Modular
Max Pressure 25 MPa
Max Flow 15 L/min
Mounting Sandwich/stack (ISO 4401)
MSA-007-X-10 Throttle-and-check modular valve 007, A-line, meter-out | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A-line, meter-out) | Control Code: X
MSA-007-Y-10 Throttle-and-check modular valve 007, A-line, meter-in | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A-line, meter-in) | Control Code: Y
MSB-007-X-10 Throttle-and-check modular valve 007, B-line, meter-out | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (B-line, meter-out) | Control Code: X
MSB-007-Y-10 Throttle-and-check modular valve 007, B-line, meter-in | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (B-line, meter-in) | Control Code: Y
MSW-007-X-10 Throttle-and-check modular valve 007, A & B line, meter-out | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A & B line, meter-out) | Control Code: X
MSW-007-Y-10 Throttle-and-check modular valve 007, A & B line, meter-in | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A & B line, meter-in) | Control Code: Y
Flow Control ModularYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — 007 Series Throttle & Check Modular Valve (Sandwich Type)

Brand Yuken·Flow Control Modular

Available part numbers (6)

MSA-007-X-10, MSA-007-Y-10, MSB-007-X-10, MSB-007-Y-10, MSW-007-X-10, MSW-007-Y-10

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSA-007-X-10Throttle-and-check modular valve 007, A-line, meter-out | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A-line, meter-out) | Control Code: X
MSA-007-Y-10Throttle-and-check modular valve 007, A-line, meter-in | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A-line, meter-in) | Control Code: Y
MSB-007-X-10Throttle-and-check modular valve 007, B-line, meter-out | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (B-line, meter-out) | Control Code: X
MSB-007-Y-10Throttle-and-check modular valve 007, B-line, meter-in | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (B-line, meter-in) | Control Code: Y
MSW-007-X-10Throttle-and-check modular valve 007, A & B line, meter-out | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A & B line, meter-out) | Control Code: X
MSW-007-Y-10Throttle-and-check modular valve 007, A & B line, meter-in | Series: 007 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A & B line, meter-in) | Control Code: Y
