• Yuken — 01 Series Relief Modular Valve (Sandwich Type)
1 1

Yuken — 01 Series Relief Modular Valve (Sandwich Type)

Yuken — 01 Series Relief Modular Valve (Sandwich Type)

01 Series Modular Valves — Relief.

Key features

  • Sandwich/stack mounting
  • Detailed specifications by inquiry

Specifications

Series 01 (1/8) Modular
Mounting Sandwich/stack (ISO 4401)
Max Pressure 35 MPa
Max Flow 60 L/min
MBP-01-B-70 Relief modular valve, P-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-B-B-70 Relief modular valve, P-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBP-01-C-70 Relief modular valve, P-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-C-B-70 Relief modular valve, P-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBP-01-H-70 Relief modular valve, P-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-H-B-70 Relief modular valve, P-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBP-01-K-70 Relief modular valve, P-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-K-B-70 Relief modular valve, P-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBA-01-B-70 Relief modular valve, A-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBA-01-C-70 Relief modular valve, A-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBA-01-H-70 Relief modular valve, A-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBA-01-K-70 Relief modular valve, A-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-B-70 Relief modular valve, B-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-C-70 Relief modular valve, B-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-H-70 Relief modular valve, B-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-K-70 Relief modular valve, B-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
Pressure Control ModularYuken
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — 01 Series Relief Modular Valve (Sandwich Type)

Brand Yuken·Pressure Control Modular

Available part numbers (16)

MBP-01-B-70, MBP-01-B-B-70, MBP-01-C-70, MBP-01-C-B-70, MBP-01-H-70, MBP-01-H-B-70, MBP-01-K-70, MBP-01-K-B-70, MBA-01-B-70, MBA-01-C-70 + 6 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MBP-01-B-70Relief modular valve, P-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-B-B-70Relief modular valve, P-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBP-01-C-70Relief modular valve, P-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-C-B-70Relief modular valve, P-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBP-01-H-70Relief modular valve, P-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-H-B-70Relief modular valve, P-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBP-01-K-70Relief modular valve, P-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: A-port side
MBP-01-K-B-70Relief modular valve, P-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | Adj. Screw: Adj. screw: B-port side
MBA-01-B-70Relief modular valve, A-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBA-01-C-70Relief modular valve, A-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBA-01-H-70Relief modular valve, A-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBA-01-K-70Relief modular valve, A-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-B-70Relief modular valve, B-line, range B | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-C-70Relief modular valve, B-line, range C | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-H-70Relief modular valve, B-line, range H | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: H: 7–21 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
MBB-01-K-70Relief modular valve, B-line, range K | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: K: 14–35 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min
