• Yuken — 01 Series Two-Pressure Reducing Modular Valve (Sandwich Type)
1 1

Yuken — 01 Series Two-Pressure Reducing Modular Valve (Sandwich Type)

Yuken — 01 Series Two-Pressure Reducing Modular Valve (Sandwich Type)

01 Series Modular Valves — Two-Pressure Reducing.

Key features

  • Sandwich/stack mounting
  • Detailed specifications by inquiry

Specifications

Series 01 (1/8) Modular
Mounting Sandwich/stack (ISO 4401)
Function Two-pressure reducing (P-line, solenoid)
Max Pressure 14 MPa
Coil (RFQ) AC A100/A200
Connection (RFQ) N: DIN
N1 DIN w/ lamp(opt)
Design -10
MRDP-01-B Two-pressure reducing modular valve, P-line, range B (solenoid switched) | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Two-pressure reducing (P-line, solenoid) | Pressure Range: B: low 0.2–3.5 / high 0.5–7 MPa | Max Pressure: 14 MPa | Max Flow: 20 L/min | Coil (RFQ): AC A100/A200 | DC D24 | AC/DC R100/R200(opt) | Connection (RFQ): N: DIN | N1: DIN w/ lamp(opt) | Design: -10
MRDP-01-C Two-pressure reducing modular valve, P-line, range C (solenoid switched) | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Two-pressure reducing (P-line, solenoid) | Pressure Range: C: low 0.5–7 / high 0.5–14 MPa | Max Pressure: 14 MPa | Max Flow: 40 L/min | Coil (RFQ): AC A100/A200 | DC D24 | AC/DC R100/R200(opt) | Connection (RFQ): N: DIN | N1: DIN w/ lamp(opt) | Design: -10
Pressure Control ModularYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — 01 Series Two-Pressure Reducing Modular Valve (Sandwich Type)

Brand Yuken·Pressure Control Modular

Available part numbers (2)

MRDP-01-B, MRDP-01-C

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MRDP-01-BTwo-pressure reducing modular valve, P-line, range B (solenoid switched) | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Two-pressure reducing (P-line, solenoid) | Pressure Range: B: low 0.2–3.5 / high 0.5–7 MPa | Max Pressure: 14 MPa | Max Flow: 20 L/min | Coil (RFQ): AC A100/A200 | DC D24 | AC/DC R100/R200(opt) | Connection (RFQ): N: DIN | N1: DIN w/ lamp(opt) | Design: -10
MRDP-01-CTwo-pressure reducing modular valve, P-line, range C (solenoid switched) | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Two-pressure reducing (P-line, solenoid) | Pressure Range: C: low 0.5–7 / high 0.5–14 MPa | Max Pressure: 14 MPa | Max Flow: 40 L/min | Coil (RFQ): AC A100/A200 | DC D24 | AC/DC R100/R200(opt) | Connection (RFQ): N: DIN | N1: DIN w/ lamp(opt) | Design: -10
