• Yuken — 03 Series Relief Modular Valve (Sandwich Type)
1 1

Yuken — 03 Series Relief Modular Valve (Sandwich Type)

Yuken — 03 Series Relief Modular Valve (Sandwich Type)

03 Series Modular Valves — Relief.

Key features

  • Sandwich/stack mounting
  • Detailed specifications by inquiry

Specifications

Max Pressure 35 MPa
Mounting Sandwich/stack (ISO 4401)
MBP-03-*-70 Relief modular valve 03, P-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: RFQ
MBA-03-*-70 Relief modular valve 03, A-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: RFQ
MBB-03-*-70 Relief modular valve 03, B-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: RFQ
MBW-03-*-70 Relief modular valve 03, A & B line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A & B line) | Pressure Range: RFQ
MBP-03-B-70 Relief modular valve, P-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBP-03-C-70 Relief modular valve, P-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBP-03-K-70 Relief modular valve, P-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBA-03-B-70 Relief modular valve, A-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBA-03-C-70 Relief modular valve, A-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBA-03-K-70 Relief modular valve, A-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBB-03-B-70 Relief modular valve, B-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBB-03-C-70 Relief modular valve, B-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBB-03-K-70 Relief modular valve, B-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBW-03-B-70 Relief modular valve, A·B-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A·B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBW-03-C-70 Relief modular valve, A·B-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A·B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBW-03-K-70 Relief modular valve, A·B-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A·B-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
Pressure Control ModularYuken
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — 03 Series Relief Modular Valve (Sandwich Type)

Brand Yuken·Pressure Control Modular

Available part numbers (16)

MBP-03-*-70, MBA-03-*-70, MBB-03-*-70, MBW-03-*-70, MBP-03-B-70, MBP-03-C-70, MBP-03-K-70, MBA-03-B-70, MBA-03-C-70, MBA-03-K-70 + 6 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MBP-03-*-70Relief modular valve 03, P-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: RFQ
MBA-03-*-70Relief modular valve 03, A-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: RFQ
MBB-03-*-70Relief modular valve 03, B-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: RFQ
MBW-03-*-70Relief modular valve 03, A & B line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A & B line) | Pressure Range: RFQ
MBP-03-B-70Relief modular valve, P-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBP-03-C-70Relief modular valve, P-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBP-03-K-70Relief modular valve, P-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (P-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBA-03-B-70Relief modular valve, A-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBA-03-C-70Relief modular valve, A-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBA-03-K-70Relief modular valve, A-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBB-03-B-70Relief modular valve, B-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBB-03-C-70Relief modular valve, B-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBB-03-K-70Relief modular valve, B-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (B-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBW-03-B-70Relief modular valve, A·B-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A·B-line) | Pressure Range: B: max 7 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBW-03-C-70Relief modular valve, A·B-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A·B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
MBW-03-K-70Relief modular valve, A·B-line, range K | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Relief (A·B-line) | Pressure Range: K: 7–35 MPa | Max Pressure: 35 MPa | Max Flow: 120 L/min
