Yuken — 03 Series Sequence / Counterbalance Modular Valve (Sandwich Type)

Yuken — 03 Series Sequence / Counterbalance Modular Valve (Sandwich Type)

03 Series Modular Valves — Sequence / Counterbalance.

Key features

  • Sandwich/stack mounting
  • Detailed specifications by inquiry

Specifications

Mounting Sandwich/stack (ISO 4401)
MHP-03-*-20 Sequence modular valve 03, P-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Sequence (P-line) | Pressure Range: RFQ
MHA-03-*-20 Counterbalance modular valve 03, A-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: RFQ
MHB-03-*-20 Counterbalance modular valve 03, B-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: RFQ
MHP-03-N-20 Sequence modular valve, P-line, range N | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Sequence (P-line) | Pressure Range: N: max 1.8 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min
MHA-03-A-20 Counterbalance modular valve, A-line, range A | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: A: 1.8–3.5 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHA-03-B-20 Counterbalance modular valve, A-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: B: 3.5–7 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHA-03-C-20 Counterbalance modular valve, A-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: C: 7–14 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHB-03-A-20 Counterbalance modular valve, B-line, range A | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: A: 1.8–3.5 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHB-03-B-20 Counterbalance modular valve, B-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: B: 3.5–7 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHB-03-C-20 Counterbalance modular valve, B-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: C: 7–14 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
Pressure Control ModularYuken
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — 03 Series Sequence / Counterbalance Modular Valve (Sandwich Type)

Brand Yuken·Pressure Control Modular

Available part numbers (10)

MHP-03-*-20, MHA-03-*-20, MHB-03-*-20, MHP-03-N-20, MHA-03-A-20, MHA-03-B-20, MHA-03-C-20, MHB-03-A-20, MHB-03-B-20, MHB-03-C-20

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MHP-03-*-20Sequence modular valve 03, P-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Sequence (P-line) | Pressure Range: RFQ
MHA-03-*-20Counterbalance modular valve 03, A-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: RFQ
MHB-03-*-20Counterbalance modular valve 03, B-line | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: RFQ
MHP-03-N-20Sequence modular valve, P-line, range N | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Sequence (P-line) | Pressure Range: N: max 1.8 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min
MHA-03-A-20Counterbalance modular valve, A-line, range A | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: A: 1.8–3.5 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHA-03-B-20Counterbalance modular valve, A-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: B: 3.5–7 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHA-03-C-20Counterbalance modular valve, A-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (A-line) | Pressure Range: C: 7–14 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHB-03-A-20Counterbalance modular valve, B-line, range A | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: A: 1.8–3.5 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHB-03-B-20Counterbalance modular valve, B-line, range B | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: B: 3.5–7 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
MHB-03-C-20Counterbalance modular valve, B-line, range C | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Counterbalance (B-line) | Pressure Range: C: 7–14 MPa | Max Pressure: 25 MPa | Max Flow: 50 L/min (free flow 70)
