• Yuken — 04 Series Reducing Modular Valve (Sandwich Type)
1 1

Yuken — 04 Series Reducing Modular Valve (Sandwich Type)

Yuken — 04 Series Reducing Modular Valve (Sandwich Type)

04 Series Modular Valves — Reducing.

Key features

  • Sandwich/stack mounting
  • Detailed specifications by inquiry

Specifications

Series 04 (1/2) Modular
Mounting Sandwich/stack (ISO 4401)
Max Pressure 35 MPa
MRP-04-A-10 Reducing modular valve, P-line, range A | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 100 L/min
MRP-04-B-10 Reducing modular valve, P-line, range B | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRP-04-C-10 Reducing modular valve, P-line, range C | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRP-04-H-10 Reducing modular valve, P-line, range H | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRA-04-A-10 Reducing modular valve, A-line, range A | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 100 L/min
MRA-04-B-10 Reducing modular valve, A-line, range B | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRA-04-C-10 Reducing modular valve, A-line, range C | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRA-04-H-10 Reducing modular valve, A-line, range H | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRB-04-A-10 Reducing modular valve, B-line, range A | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 100 L/min
MRB-04-B-10 Reducing modular valve, B-line, range B | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRB-04-C-10 Reducing modular valve, B-line, range C | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRB-04-H-10 Reducing modular valve, B-line, range H | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
Pressure Control ModularYuken
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — 04 Series Reducing Modular Valve (Sandwich Type)

Brand Yuken·Pressure Control Modular

Available part numbers (12)

MRP-04-A-10, MRP-04-B-10, MRP-04-C-10, MRP-04-H-10, MRA-04-A-10, MRA-04-B-10, MRA-04-C-10, MRA-04-H-10, MRB-04-A-10, MRB-04-B-10 + 2 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MRP-04-A-10Reducing modular valve, P-line, range A | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 100 L/min
MRP-04-B-10Reducing modular valve, P-line, range B | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRP-04-C-10Reducing modular valve, P-line, range C | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRP-04-H-10Reducing modular valve, P-line, range H | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (P-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRA-04-A-10Reducing modular valve, A-line, range A | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 100 L/min
MRA-04-B-10Reducing modular valve, A-line, range B | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRA-04-C-10Reducing modular valve, A-line, range C | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRA-04-H-10Reducing modular valve, A-line, range H | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (A-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRB-04-A-10Reducing modular valve, B-line, range A | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: A: 0.7–7 MPa | Max Pressure: 35 MPa | Max Flow: 100 L/min
MRB-04-B-10Reducing modular valve, B-line, range B | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: B: 1.5–7 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRB-04-C-10Reducing modular valve, B-line, range C | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: C: 3.5–14 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min
MRB-04-H-10Reducing modular valve, B-line, range H | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure reducing (B-line) | Pressure Range: H: 7–25 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min

Need a different model, or a part not listed here? Send us your parts list →
