• Yuken 50T Single Vane Pump (fixed displacement, 7 MPa)
1 1

Yuken 50T Single Vane Pump (fixed displacement, 7 MPa)

Yuken 50T Single Vane Pump (fixed displacement, 7 MPa)

Single Vane Pumps (50T series).

Key features

  • Stable performance over a wide flow range, widely used as a hydraulic power source
  • Max working pressure 7 MPa
  • Foot and flange mounting types
  • Detailed configuration by separate inquiry (RFQ)

Specifications

Series 50T
Type Single Vane Pump (fixed displacement)
Max Working Pressure 7 MPa (mineral / general / phosphate-ester)
Permissible Speed max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min)
Mounting Foot or Flange type
Mass (approx) 10.5 kg (foot) / 9.0 kg (flange)
Note Detailed specification / configuration: RFQ
Fluid Option Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-7 50T single vane pump, 6.8 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 6.8 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-12 50T single vane pump, 11.6 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 11.6 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-17 50T single vane pump, 16.5 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 16.5 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-23 50T single vane pump, 22.9 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 22.9 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-26 50T single vane pump, 25.9 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 25.9 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-36 50T single vane pump, 36.0 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 36.0 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
Single Vane PumpsYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken 50T Single Vane Pump (fixed displacement, 7 MPa)

Brand Yuken·Single Vane Pumps

Available part numbers (6)

50T-7, 50T-12, 50T-17, 50T-23, 50T-26, 50T-36

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
50T-750T single vane pump, 6.8 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 6.8 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-1250T single vane pump, 11.6 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 11.6 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-1750T single vane pump, 16.5 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 16.5 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-2350T single vane pump, 22.9 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 22.9 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-2650T single vane pump, 25.9 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 25.9 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)
50T-3650T single vane pump, 36.0 cm3/rev, 7 MPa | Series: 50T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 36.0 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1800-2000 / min 600-800 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 10.5 kg (foot) / 9.0 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals)

Need a different model, or a part not listed here? Send us your parts list →
