Yuken A3H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 16.3-180.7 cm3/rev)

Yuken A3H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 16.3-180.7 cm3/rev)

"A3H" Series Variable Displacement Piston Pumps - Single Pump, Pressure Compensator Type.

Specifications

Series A3H
Direction of Rotation Clockwise (viewed from shaft end)
Control Type Pressure Compensator (01)
Pressure Adjustment Range K (5-35 MPa)
Rated Pressure 28 MPa
Shaft End Parallel key (K)
Design Number 10
Max. Working Pressure 35 MPa
A3H16-FR01KK-10 Yuken A3H16 (16.3 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Mass: 14.5 kg (flange) / 23.4 kg (foot)
A3H16-LR01KK-10 Yuken A3H16 (16.3 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Mass: 14.5 kg (flange) / 23.4 kg (foot)
A3H37-FR01KK-10 Yuken A3H37 (37.1 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Mass: 19.5 kg (flange) / 27.0 kg (foot)
A3H37-LR01KK-10 Yuken A3H37 (37.1 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Mass: 19.5 kg (flange) / 27.0 kg (foot)
A3H56-FR01KK-10 Yuken A3H56 (56.3 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Mass: 25.7 kg (flange) / 33.2 kg (foot)
A3H56-LR01KK-10 Yuken A3H56 (56.3 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Mass: 25.7 kg (flange) / 33.2 kg (foot)
A3H71-FR01KK-10 Yuken A3H71 (70.7 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Mass: 35.0 kg (flange) / 42.5 kg (foot)
A3H71-LR01KK-10 Yuken A3H71 (70.7 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Mass: 35.0 kg (flange) / 42.5 kg (foot)
A3H100-FR01KK-10 Yuken A3H100 (100.5 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Mass: 44.9 kg (flange) / 72.9 kg (foot)
A3H100-LR01KK-10 Yuken A3H100 (100.5 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Mass: 44.9 kg (flange) / 72.9 kg (foot)
A3H145-FR01KK-10 Yuken A3H145 (145.2 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 60.0 kg (flange) / 88.0 kg (foot)
A3H145-LR01KK-10 Yuken A3H145 (145.2 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 60.0 kg (flange) / 88.0 kg (foot)
A3H180-FR01KK-10 Yuken A3H180 (180.7 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 70.4 kg (flange) / 98.4 kg (foot)
A3H180-LR01KK-10 Yuken A3H180 (180.7 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 70.4 kg (flange) / 98.4 kg (foot)
Piston PumpsYuken
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken A3H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 16.3-180.7 cm3/rev)

Brand Yuken·Piston Pumps

Available part numbers (14)

A3H16-FR01KK-10, A3H16-LR01KK-10, A3H37-FR01KK-10, A3H37-LR01KK-10, A3H56-FR01KK-10, A3H56-LR01KK-10, A3H71-FR01KK-10, A3H71-LR01KK-10, A3H100-FR01KK-10, A3H100-LR01KK-10 + 4 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
A3H16-FR01KK-10Yuken A3H16 (16.3 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Mass: 14.5 kg (flange) / 23.4 kg (foot)
A3H16-LR01KK-10Yuken A3H16 (16.3 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Mass: 14.5 kg (flange) / 23.4 kg (foot)
A3H37-FR01KK-10Yuken A3H37 (37.1 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Mass: 19.5 kg (flange) / 27.0 kg (foot)
A3H37-LR01KK-10Yuken A3H37 (37.1 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Mass: 19.5 kg (flange) / 27.0 kg (foot)
A3H56-FR01KK-10Yuken A3H56 (56.3 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Mass: 25.7 kg (flange) / 33.2 kg (foot)
A3H56-LR01KK-10Yuken A3H56 (56.3 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Mass: 25.7 kg (flange) / 33.2 kg (foot)
A3H71-FR01KK-10Yuken A3H71 (70.7 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Mass: 35.0 kg (flange) / 42.5 kg (foot)
A3H71-LR01KK-10Yuken A3H71 (70.7 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Mass: 35.0 kg (flange) / 42.5 kg (foot)
A3H100-FR01KK-10Yuken A3H100 (100.5 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Mass: 44.9 kg (flange) / 72.9 kg (foot)
A3H100-LR01KK-10Yuken A3H100 (100.5 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Mass: 44.9 kg (flange) / 72.9 kg (foot)
A3H145-FR01KK-10Yuken A3H145 (145.2 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 60.0 kg (flange) / 88.0 kg (foot)
A3H145-LR01KK-10Yuken A3H145 (145.2 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 60.0 kg (flange) / 88.0 kg (foot)
A3H180-FR01KK-10Yuken A3H180 (180.7 cm3/rev) high-pressure Pressure Compensator, Flange mount | Series: A3H | Frame: A3H180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130.0 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 70.4 kg (flange) / 98.4 kg (foot)
A3H180-LR01KK-10Yuken A3H180 (180.7 cm3/rev) high-pressure Pressure Compensator, Foot mount | Series: A3H | Frame: A3H180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130.0 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Pressure Adjustment Range: K (5-35 MPa) | Rated Pressure: 28 MPa | Shaft End: Parallel key (K) | Design Number: 10 | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Mass: 70.4 kg (flange) / 98.4 kg (foot)
