Yuken A3HG Series High Pressure Variable Displacement Piston Pump (External Pilot Pressure Compensator, 16.3-180.7 cm3/rev)

Yuken A3HG Series High Pressure Variable Displacement Piston Pump (External Pilot Pressure Compensator, 16.3-180.7 cm3/rev)

"A3HG" Series Variable Displacement Piston Pumps - Pilot Pressure Control Type Pressure Compensator.

Specifications

Series A3HG
Direction of Rotation Clockwise (viewed from shaft end)
Control Type External Pilot Pressure Compensator (07)
Rated Pressure 31.5 MPa
Max. Working Pressure 35 MPa
Shaft End K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ)
Port / Thread Standard E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ)
Mounting Bolts 2 (C) or 4 (D) - specify at order (RFQ)
Thru-Drive 2nd pump mounting (thru-drive) available - RFQ
Design Number 10
Mass Varies by configuration
A3HG16-FR07-10 Yuken A3HG16 (16.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG16-LR07-10 Yuken A3HG16 (16.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG37-FR07-10 Yuken A3HG37 (37.1 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG37-LR07-10 Yuken A3HG37 (37.1 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG56-FR07-10 Yuken A3HG56 (56.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG56-LR07-10 Yuken A3HG56 (56.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG71-FR07-10 Yuken A3HG71 (70.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG71-LR07-10 Yuken A3HG71 (70.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG100-FR07-10 Yuken A3HG100 (100.5 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG100-LR07-10 Yuken A3HG100 (100.5 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG145-FR07-10 Yuken A3HG145 (145.2 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG145-LR07-10 Yuken A3HG145 (145.2 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG180-FR07-10 Yuken A3HG180 (180.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG180-LR07-10 Yuken A3HG180 (180.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
Piston PumpsYuken
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken A3HG Series High Pressure Variable Displacement Piston Pump (External Pilot Pressure Compensator, 16.3-180.7 cm3/rev)

Brand Yuken·Piston Pumps

Available part numbers (14)

A3HG16-FR07-10, A3HG16-LR07-10, A3HG37-FR07-10, A3HG37-LR07-10, A3HG56-FR07-10, A3HG56-LR07-10, A3HG71-FR07-10, A3HG71-LR07-10, A3HG100-FR07-10, A3HG100-LR07-10 + 4 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
A3HG16-FR07-10Yuken A3HG16 (16.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG16-LR07-10Yuken A3HG16 (16.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG16 | Geometric Displacement: 16.3 cm3/rev | Min. Adjustment Flow: 8 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-3600 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG37-FR07-10Yuken A3HG37 (37.1 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG37-LR07-10Yuken A3HG37 (37.1 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG56-FR07-10Yuken A3HG56 (56.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG56-LR07-10Yuken A3HG56 (56.3 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG71-FR07-10Yuken A3HG71 (70.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG71-LR07-10Yuken A3HG71 (70.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG100-FR07-10Yuken A3HG100 (100.5 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG100-LR07-10Yuken A3HG100 (100.5 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG145-FR07-10Yuken A3HG145 (145.2 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG145-LR07-10Yuken A3HG145 (145.2 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG180-FR07-10Yuken A3HG180 (180.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Flange mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG180-LR07-10Yuken A3HG180 (180.7 cm3/rev) ISO high-pressure External Pilot Pressure Compensator, Foot mount; shaft/port/bolt specified at order | Series: A3HG | Frame: A3HG180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Pressure Compensator (07) | Min. Adjustment Pressure: 6 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
