• Yuken A7H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 180-270 cm3/rev)
1 1

Yuken A7H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 180-270 cm3/rev)

Yuken A7H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 180-270 cm3/rev)

"A7H" Series Variable Displacement Piston Pumps - Single Pump, Pressure Compensator Type.

Specifications

Series A7H
Direction of Rotation Clockwise (viewed from shaft end)
Control Type Pressure Compensator (01)
Min. Flow Adjustment Provided
Port Position Side port
Rated Pressure 35 MPa
Max. Working Pressure 40 MPa
Design Number 11
A7H180-FR01S-11 Yuken A7H180 (180 cm3/rev) pressure compensator, Flange mount | Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H180-LR01S-11 Yuken A7H180 (180 cm3/rev) pressure compensator, Foot mount | Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-FR01S-11 Yuken A7H265 (270 cm3/rev) pressure compensator, Flange mount | Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-LR01S-11 Yuken A7H265 (270 cm3/rev) pressure compensator, Foot mount | Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
Piston PumpsYuken
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken A7H Series High Pressure Variable Displacement Piston Pump (Pressure Compensator, 180-270 cm3/rev)

Brand Yuken·Piston Pumps

Available part numbers (4)

A7H180-FR01S-11, A7H180-LR01S-11, A7H265-FR01S-11, A7H265-LR01S-11

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
A7H180-FR01S-11Yuken A7H180 (180 cm3/rev) pressure compensator, Flange mount | Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H180-LR01S-11Yuken A7H180 (180 cm3/rev) pressure compensator, Foot mount | Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-FR01S-11Yuken A7H265 (270 cm3/rev) pressure compensator, Flange mount | Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-LR01S-11Yuken A7H265 (270 cm3/rev) pressure compensator, Foot mount | Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Pressure Compensator (01) | Min. Flow Adjustment: Provided | Port Position: Side port | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
