Yuken AMN-G/W Power Amplifiers for Shockless Directional & Flow Control Valve (EDFG-01)

Yuken AMN-G/W Power Amplifiers for Shockless Directional & Flow Control Valve (EDFG-01)

Yuken DC24V power amplifiers for the shockless-type proportional directional & flow control valve EDFG-01.

Key features

  • Two types: AMN-G-10 is a shockless pattern (sequence-input) amplifier with selectable output patterns and slope-time setting; AMN-W-10 is a DC analog-input amplifier with a delay function
  • Both: max output current 1.3 A (10Ω solenoid), variable dither, temperature drift 0.2 mA/°C, supply DC24V (20–30 V incl. ripple), 25 W, mass 0.2 kg
  • No power switch (operates as soon as powered — fit an external switch)

Specifications

Type Power amplifier for shockless directional & flow control valve (EDFG-01)
Brand Yuken
Max Output Current 1.3 A (10Ω solenoid)
Dither variable
Temp Drift 0.2 mA/°C
Power Supply DC24V (20–30 V incl. ripple)
Power Consumption 25 W
Mass 0.2 kg
Drives EDFG-01 shockless directional & flow valve
Design No. 10
AMN-G-10 Yuken AMN-G-10 power amplifier for EDFG-01 shockless directional & flow valve | Type: Power amplifier for shockless directional & flow control valve (EDFG-01) | Brand: Yuken | Model: AMN-G-10 | Function: G (shockless / pattern type) | Max Output Current: 1.3 A (10Ω solenoid) | Features: Sequence-input shockless control: setting resolution 0–99% in 1% steps, 3 output patterns each for SOL a and SOL b, slope (ramp) time 1–99 s (0–99% adjust). Sequence input 10 mA/24 V, input voltage range 10–28 V. | Dither: variable | Temp Drift: 0.2 mA/°C | Power Supply: DC24V (20–30 V incl. ripple) | Power Consumption: 25 W | Mass: 0.2 kg | Drives: EDFG-01 shockless directional & flow valve | Design No.: 10
AMN-W-10 Yuken AMN-W-10 power amplifier for EDFG-01 shockless directional & flow valve | Type: Power amplifier for shockless directional & flow control valve (EDFG-01) | Brand: Yuken | Model: AMN-W-10 | Function: W (DC input / analog type) | Max Output Current: 1.3 A (10Ω solenoid) | Features: DC analog input: SOL a at DC -10 V, SOL b at DC +10 V; input impedance 10 kΩ, max gain 1.3 A/±5 V, delay-time adjustment 0.1–3 s. | Dither: variable | Temp Drift: 0.2 mA/°C | Power Supply: DC24V (20–30 V incl. ripple) | Power Consumption: 25 W | Mass: 0.2 kg | Drives: EDFG-01 shockless directional & flow valve | Design No.: 10
Proportional Valve AmplifiersYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken AMN-G/W Power Amplifiers for Shockless Directional & Flow Control Valve (EDFG-01)

Brand Yuken·Proportional Valve Amplifiers

Available part numbers (2)

AMN-G-10, AMN-W-10

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AMN-G-10Yuken AMN-G-10 power amplifier for EDFG-01 shockless directional & flow valve | Type: Power amplifier for shockless directional & flow control valve (EDFG-01) | Brand: Yuken | Model: AMN-G-10 | Function: G (shockless / pattern type) | Max Output Current: 1.3 A (10Ω solenoid) | Features: Sequence-input shockless control: setting resolution 0–99% in 1% steps, 3 output patterns each for SOL a and SOL b, slope (ramp) time 1–99 s (0–99% adjust). Sequence input 10 mA/24 V, input voltage range 10–28 V. | Dither: variable | Temp Drift: 0.2 mA/°C | Power Supply: DC24V (20–30 V incl. ripple) | Power Consumption: 25 W | Mass: 0.2 kg | Drives: EDFG-01 shockless directional & flow valve | Design No.: 10
AMN-W-10Yuken AMN-W-10 power amplifier for EDFG-01 shockless directional & flow valve | Type: Power amplifier for shockless directional & flow control valve (EDFG-01) | Brand: Yuken | Model: AMN-W-10 | Function: W (DC input / analog type) | Max Output Current: 1.3 A (10Ω solenoid) | Features: DC analog input: SOL a at DC -10 V, SOL b at DC +10 V; input impedance 10 kΩ, max gain 1.3 A/±5 V, delay-time adjustment 0.1–3 s. | Dither: variable | Temp Drift: 0.2 mA/°C | Power Supply: DC24V (20–30 V incl. ripple) | Power Consumption: 25 W | Mass: 0.2 kg | Drives: EDFG-01 shockless directional & flow valve | Design No.: 10
