Yuken AR Series Variable Displacement Piston Pump (Pressure Compensator, 15.8 / 22.2 cm3/rev)

"AR" Series Variable Displacement Piston Pumps - Single Pump, Pressure Compensator Type.

Specifications

Series	AR
Mounting	Flange
Direction of Rotation	Clockwise (viewed from shaft end)
Control Type	Pressure Compensator
Design Number	22
Rated Pressure	16 MPa
Allowable Speed	600-1800 r/min
Port Connections	Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4

AR16-FR01B-22		Yuken AR16 (15.8 cm3/rev), Flange mount, Axial port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR16-FR01BS-22		Yuken AR16 (15.8 cm3/rev), Flange mount, Side port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR16-FR01C-22		Yuken AR16 (15.8 cm3/rev), Flange mount, Axial port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR16-FR01CS-22		Yuken AR16 (15.8 cm3/rev), Flange mount, Side port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01B-22		Yuken AR22 (22.2 cm3/rev), Flange mount, Axial port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01BS-22		Yuken AR22 (22.2 cm3/rev), Flange mount, Side port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01C-22		Yuken AR22 (22.2 cm3/rev), Flange mount, Axial port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
AR22-FR01CS-22		Yuken AR22 (22.2 cm3/rev), Flange mount, Side port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4

Piston PumpsYuken

8 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken AR Series Variable Displacement Piston Pump (Pressure Compensator, 15.8 / 22.2 cm3/rev)

Brand Yuken·Piston Pumps

Available part numbers (8)

AR16-FR01B-22, AR16-FR01BS-22, AR16-FR01C-22, AR16-FR01CS-22, AR22-FR01B-22, AR22-FR01BS-22, AR22-FR01C-22, AR22-FR01CS-22

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	AR16-FR01B-22	Yuken AR16 (15.8 cm3/rev), Flange mount, Axial port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR16-FR01BS-22	Yuken AR16 (15.8 cm3/rev), Flange mount, Side port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR16-FR01C-22	Yuken AR16 (15.8 cm3/rev), Flange mount, Axial port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR16-FR01CS-22	Yuken AR16 (15.8 cm3/rev), Flange mount, Side port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR16 \| Geometric Displacement: 15.8 cm3/rev \| Min. Adjustment Flow: 6.0 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 11.8 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR22-FR01B-22	Yuken AR22 (22.2 cm3/rev), Flange mount, Axial port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR22-FR01BS-22	Yuken AR22 (22.2 cm3/rev), Flange mount, Side port, pressure range B (1.2-7 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 1.2-7 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR22-FR01C-22	Yuken AR22 (22.2 cm3/rev), Flange mount, Axial port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Axial port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4
	AR22-FR01CS-22	Yuken AR22 (22.2 cm3/rev), Flange mount, Side port, pressure range C (2.0-16 MPa) \| Series: AR \| Frame: AR22 \| Geometric Displacement: 22.2 cm3/rev \| Min. Adjustment Flow: 8.5 cm3/rev \| Mounting: Flange \| Direction of Rotation: Clockwise (viewed from shaft end) \| Control Type: Pressure Compensator \| Pressure Adjustment Range: 2.0-16 MPa \| Port Position: Side port \| Design Number: 22 \| Rated Pressure: 16 MPa \| Allowable Speed: 600-1800 r/min \| Mass: 12.5 kg \| Port Connections: Suction S dia.19 (flange), Delivery P Rc3/4, Drain DR Rc3/8, Gauge PG Rc1/4

Need a different model, or a part not listed here? Send us your parts list →
