Yuken — DSG-01 Explosion Proof (Increased Safety) Solenoid Operated Directional Valve

Yuken — DSG-01 Explosion Proof (Increased Safety) Solenoid Operated Directional Valve

Explosion Proof (Increased Safety) Type Solenoid Operated Directional Valves, DSG-01 (eG3).

Key features

  • Increased-safety construction (recommended for class 2 areas): max. operating pressure 31.5 MPa (spool 60) / 25 MPa, max. flow 63 L/min, tank back pressure 16 MPa
  • Subplate mounting

Specifications

Type Explosion-proof Increased Safety (Solenoid Operated)
Valve Size 01 (Rc 1/8)
Max Pressure 31.5 MPa (spool 60) / 25 MPa
Max Flow 63 L/min
Explosion-proof Class eG3
Mounting Subplate (ISO 4401)
Spool Selection Per base DSG model table (RFQ)
Coil DC / rectified R type (RFQ)
Design No. 51
DSG-01-3C*-eG3-51 DSG-01 explosion-proof (Increased Safety) solenoid directional valve, spool group 3C (3-position, spring centered) | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 31.5 MPa (spool 60) / 25 MPa | Max Flow: 63 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 3Cx (per base DSG-01 table) | Spring: 3-position, spring centered | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 51
DSG-01-2D2-eG3-51 DSG-01 explosion-proof (Increased Safety) solenoid directional valve, spool group 2D2 (2-position, no-spring detented) | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 31.5 MPa (spool 60) / 25 MPa | Max Flow: 63 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 2D2 | Spring: 2-position, no-spring detented | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 51
DSG-01-2B*-eG3-51 DSG-01 explosion-proof (Increased Safety) solenoid directional valve, spool group 2B (2-position, spring offset) | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 31.5 MPa (spool 60) / 25 MPa | Max Flow: 63 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 2Bx (per base DSG-01 table) | Spring: 2-position, spring offset | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 51
Solenoid OperatedYuken
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — DSG-01 Explosion Proof (Increased Safety) Solenoid Operated Directional Valve

Brand Yuken·Solenoid Operated

Available part numbers (3)

DSG-01-3C*-eG3-51, DSG-01-2D2-eG3-51, DSG-01-2B*-eG3-51

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DSG-01-3C*-eG3-51DSG-01 explosion-proof (Increased Safety) solenoid directional valve, spool group 3C (3-position, spring centered) | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 31.5 MPa (spool 60) / 25 MPa | Max Flow: 63 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 3Cx (per base DSG-01 table) | Spring: 3-position, spring centered | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 51
DSG-01-2D2-eG3-51DSG-01 explosion-proof (Increased Safety) solenoid directional valve, spool group 2D2 (2-position, no-spring detented) | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 31.5 MPa (spool 60) / 25 MPa | Max Flow: 63 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 2D2 | Spring: 2-position, no-spring detented | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 51
DSG-01-2B*-eG3-51DSG-01 explosion-proof (Increased Safety) solenoid directional valve, spool group 2B (2-position, spring offset) | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 31.5 MPa (spool 60) / 25 MPa | Max Flow: 63 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 2Bx (per base DSG-01 table) | Spring: 2-position, spring offset | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 51
