Yuken EBG-10 Proportional Relief Valve (E series, 24.5 MPa, max 400 L/min, size 10)

Yuken EBG-10 Proportional Relief Valve (E series, 24.5 MPa, max 400 L/min, size 10)

Proportional Electro-Hydraulic Relief Valves.

Key features

  • E-series current-driven valve integrating the compact high-performance 1/8 proportional pilot relief valve with a low-noise relief valve; controls system pressure proportionally to the input current
  • Use together with a dedicated Yuken power amplifier
  • Sub-plate mounting, valve size 10
  • Max operating pressure 24.5 MPa, max flow 400 L/min, min flow 3 L/min
  • Pressure adjustment range C: up to 15.7 MPa / H: up to 24.5 MPa
  • Coil resistance 10Ω, hysteresis 3%

Specifications

Type Proportional Relief Valve (E series, current-driven)
Series EBG
Mounting Sub-plate (G)
Valve Size 10
Max Flow 400 L/min
Coil 10Ω
Drive Current input (use with dedicated power amplifier)
Mass 10 kg
Design No. 51
EBG-10-C-51 EBG-10 Relief (E), C up to 15.7 MPa, Built-in safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: C (up to 15.7 MPa) | Max Pressure: 15.7 MPa | Safety Valve: Built-in safety valve | Rated Current: 730 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
EBG-10-C-T-51 EBG-10 Relief (E), C up to 15.7 MPa, Without safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: C (up to 15.7 MPa) | Max Pressure: 15.7 MPa | Safety Valve: Without safety valve | Rated Current: 730 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
EBG-10-H-51 EBG-10 Relief (E), H up to 24.5 MPa, Built-in safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: H (up to 24.5 MPa) | Max Pressure: 24.5 MPa | Safety Valve: Built-in safety valve | Rated Current: 780 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
EBG-10-H-T-51 EBG-10 Relief (E), H up to 24.5 MPa, Without safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: H (up to 24.5 MPa) | Max Pressure: 24.5 MPa | Safety Valve: Without safety valve | Rated Current: 780 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
Proportional Relief ValvesYuken
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EBG-10 Proportional Relief Valve (E series, 24.5 MPa, max 400 L/min, size 10)

Brand Yuken·Proportional Relief Valves

Available part numbers (4)

EBG-10-C-51, EBG-10-C-T-51, EBG-10-H-51, EBG-10-H-T-51

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EBG-10-C-51EBG-10 Relief (E), C up to 15.7 MPa, Built-in safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: C (up to 15.7 MPa) | Max Pressure: 15.7 MPa | Safety Valve: Built-in safety valve | Rated Current: 730 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
EBG-10-C-T-51EBG-10 Relief (E), C up to 15.7 MPa, Without safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: C (up to 15.7 MPa) | Max Pressure: 15.7 MPa | Safety Valve: Without safety valve | Rated Current: 730 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
EBG-10-H-51EBG-10 Relief (E), H up to 24.5 MPa, Built-in safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: H (up to 24.5 MPa) | Max Pressure: 24.5 MPa | Safety Valve: Built-in safety valve | Rated Current: 780 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
EBG-10-H-T-51EBG-10 Relief (E), H up to 24.5 MPa, Without safety valve, max 400 L/min | Type: Proportional Relief Valve (E series, current-driven) | Series: EBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 400 L/min | Pressure Adj. Range: H (up to 24.5 MPa) | Max Pressure: 24.5 MPa | Safety Valve: Without safety valve | Rated Current: 780 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51
