Yuken EDFHG-06 Proportional Directional & Flow Control Valve (E series, 25 MPa, rated 280 L/min, size 06)

Yuken EDFHG-06 Proportional Directional & Flow Control Valve (E series, 25 MPa, rated 280 L/min, size 06)

Proportional Electro-Hydraulic Directional and Flow Control Valves.

Key features

  • A two-stage directional/flow valve that uses a proportional reducing valve with two proportional solenoids as its pilot: flow is controlled by converting the input current in the solenoid, and direction is set by which of the two solenoids is energised
  • Used with a dedicated Yuken power amplifier, it handles actuator speed, acceleration/deceleration and direction in a single valve, simplifying the circuit and cutting cost
  • Sub-plate mounting, valve size 06
  • Max operating pressure 25 MPa, rated flow 280 L/min, pilot pressure 1.5–16 MPa, tank port pressure 21 MPa, rated current 900 mA, coil 10Ω. Spool forms 3C2/3C40; meter-in/meter-out (XY); internal/external pilot

Specifications

Type Proportional Directional & Flow Control Valve (E series, 2-stage)
Series EDFHG
Mounting Sub-plate
Valve Size 06
Rated Flow 280 L/min
Max Pressure 25 MPa
Pilot Pressure 1.5–16 MPa
Tank Port Pressure 21 MPa
Control Direction XY (meter-in/meter-out)
Rated Current 900 mA
Coil 10Ω
Drive Current input (use with dedicated power amplifier)
EDFHG-06-280-3C2-XY-E-31 EDFHG-06 Dir&Flow (E), 3C2, External pilot (standard), rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C2 | Control Direction: XY (meter-in/meter-out) | Pilot: External pilot (standard) | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
EDFHG-06-280-3C2-XY-31 EDFHG-06 Dir&Flow (E), 3C2, Internal pilot, rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C2 | Control Direction: XY (meter-in/meter-out) | Pilot: Internal pilot | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
EDFHG-06-280-3C40-XY-E-31 EDFHG-06 Dir&Flow (E), 3C40, External pilot (standard), rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C40 | Control Direction: XY (meter-in/meter-out) | Pilot: External pilot (standard) | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
EDFHG-06-280-3C40-XY-31 EDFHG-06 Dir&Flow (E), 3C40, Internal pilot, rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C40 | Control Direction: XY (meter-in/meter-out) | Pilot: Internal pilot | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
Proportional Directional & FlowYuken
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EDFHG-06 Proportional Directional & Flow Control Valve (E series, 25 MPa, rated 280 L/min, size 06)

Brand Yuken·Proportional Directional & Flow

Available part numbers (4)

EDFHG-06-280-3C2-XY-E-31, EDFHG-06-280-3C2-XY-31, EDFHG-06-280-3C40-XY-E-31, EDFHG-06-280-3C40-XY-31

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EDFHG-06-280-3C2-XY-E-31EDFHG-06 Dir&Flow (E), 3C2, External pilot (standard), rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C2 | Control Direction: XY (meter-in/meter-out) | Pilot: External pilot (standard) | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
EDFHG-06-280-3C2-XY-31EDFHG-06 Dir&Flow (E), 3C2, Internal pilot, rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C2 | Control Direction: XY (meter-in/meter-out) | Pilot: Internal pilot | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
EDFHG-06-280-3C40-XY-E-31EDFHG-06 Dir&Flow (E), 3C40, External pilot (standard), rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C40 | Control Direction: XY (meter-in/meter-out) | Pilot: External pilot (standard) | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
EDFHG-06-280-3C40-XY-31EDFHG-06 Dir&Flow (E), 3C40, Internal pilot, rated 280 L/min | Type: Proportional Directional & Flow Control Valve (E series, 2-stage) | Series: EDFHG | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 280 L/min | Max Pressure: 25 MPa | Pilot Pressure: 1.5–16 MPa | Tank Port Pressure: 21 MPa | Spool Form: 3C40 | Control Direction: XY (meter-in/meter-out) | Pilot: Internal pilot | Rated Current: 900 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 31
