Yuken EFBG-10 10Ω-10Ω Proportional Power-Saving Valve (E series, 24.5 MPa, max 500 L/min, size 10)

Yuken EFBG-10 10Ω-10Ω Proportional Power-Saving Valve (E series, 24.5 MPa, max 500 L/min, size 10)

10Ω-10Ω Series Proportional Electro-Hydraulic Flow Control and Relief Valves.

Key features

  • Use with a dedicated Yuken power amplifier
  • Sub-plate mounting, valve size 10
  • Max operating pressure 24.5 MPa, max flow 500 L/min (5–500 L/min)
  • Pilot-relief pressure range C: 1.5–15.7 MPa / H: 1.5–24.5 MPa; or no pilot relief valve (safety valve built-in)
  • Internal/external pilot
  • Coil 10Ω

Specifications

Type Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven)
Series EFBG (10Ω-10Ω)
Mounting Sub-plate (G)
Valve Size 10
Max Adjustable Flow 500 L/min
Flow Adj. Range 5–500 L/min
Max Pressure 24.5 MPa
Flow-control Rated Current 900 mA
Valve Pressure Drop 0.9 MPa
Coil 10Ω
Drive Current input (use with dedicated power amplifier)
Design No. 51
EFBG-10-500-C-51 EFBG-10 Power-Saving (E), 500L/min, pilot relief C, Internal pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: C (1.5–15.7 MPa), rated current 800 mA | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-C-E-51 EFBG-10 Power-Saving (E), 500L/min, pilot relief C, External pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: C (1.5–15.7 MPa), rated current 800 mA | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-H-51 EFBG-10 Power-Saving (E), 500L/min, pilot relief H, Internal pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: H (1.5–24.5 MPa), rated current 900 mA | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-H-E-51 EFBG-10 Power-Saving (E), 500L/min, pilot relief H, External pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: H (1.5–24.5 MPa), rated current 900 mA | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-51 EFBG-10 Power-Saving (E), 500L/min, no pilot relief valve (safety valve built-in), Internal pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief: None (safety valve built-in), max adjustment pressure 24.5 MPa | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-E-51 EFBG-10 Power-Saving (E), 500L/min, no pilot relief valve (safety valve built-in), External pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief: None (safety valve built-in), max adjustment pressure 24.5 MPa | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
Proportional Power SavingYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EFBG-10 10Ω-10Ω Proportional Power-Saving Valve (E series, 24.5 MPa, max 500 L/min, size 10)

Brand Yuken·Proportional Power Saving

Available part numbers (6)

EFBG-10-500-C-51, EFBG-10-500-C-E-51, EFBG-10-500-H-51, EFBG-10-500-H-E-51, EFBG-10-500-51, EFBG-10-500-E-51

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EFBG-10-500-C-51EFBG-10 Power-Saving (E), 500L/min, pilot relief C, Internal pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: C (1.5–15.7 MPa), rated current 800 mA | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-C-E-51EFBG-10 Power-Saving (E), 500L/min, pilot relief C, External pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: C (1.5–15.7 MPa), rated current 800 mA | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-H-51EFBG-10 Power-Saving (E), 500L/min, pilot relief H, Internal pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: H (1.5–24.5 MPa), rated current 900 mA | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-H-E-51EFBG-10 Power-Saving (E), 500L/min, pilot relief H, External pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: H (1.5–24.5 MPa), rated current 900 mA | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-51EFBG-10 Power-Saving (E), 500L/min, no pilot relief valve (safety valve built-in), Internal pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief: None (safety valve built-in), max adjustment pressure 24.5 MPa | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
EFBG-10-500-E-51EFBG-10 Power-Saving (E), 500L/min, no pilot relief valve (safety valve built-in), External pilot | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief: None (safety valve built-in), max adjustment pressure 24.5 MPa | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51
