Yuken EFCG-10 40Ω Proportional Flow Control Valve with built-in check valve (E series, 20.6 MPa, size 10)

Yuken EFCG-10 40Ω Proportional Flow Control Valve with built-in check valve (E series, 20.6 MPa, size 10)

40Ω Series Proportional Electro-Hydraulic Flow Control Valves.

Key features

  • Suited to shock-free start/stop/speed-change of actuators
  • Use with a dedicated Yuken power amplifier
  • Sub-plate mounting, valve size 10
  • Max operating pressure 20.6 MPa, max adjustable flow 500 L/min, rated current 700 mA
  • Coil resistance 45Ω (40Ω series), hysteresis 7%
  • Optional pressure-compensation piston opening-adjustment screw (N)

Specifications

Type Proportional Flow Control Valve (E series, current-driven, 40Ω) with built-in Check
Series EFCG
Mounting Sub-plate (G)
Valve Size 10
Max Adjustable Flow 500 L/min
Flow Adj. Range 5–500 L/min
Max Pressure 20.6 MPa
Free Flow (check) 550 L/min
Rated Current 700 mA
Coil 45Ω
Pressure/Temperature compensated Yes
Hysteresis 7%
EFCG-10-500-11 EFCG-10 40ohm Flow Control +Check (E), 500L/min, N-opt: none | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 550 L/min | Pressure-comp. Adjustment Screw: None | Rated Current: 700 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 7% | Drive: Current input (use with dedicated power amplifier) | Mass: 51 kg | Design No.: 11
EFCG-10-500-N-11 EFCG-10 40ohm Flow Control +Check (E), 500L/min, N-opt: N | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 550 L/min | Pressure-comp. Adjustment Screw: Pressure-compensation piston opening-adjustment screw (made to order — consult) | Rated Current: 700 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 7% | Drive: Current input (use with dedicated power amplifier) | Mass: 51 kg | Design No.: 11
Proportional Flow ControlYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EFCG-10 40Ω Proportional Flow Control Valve with built-in check valve (E series, 20.6 MPa, size 10)

Brand Yuken·Proportional Flow Control

Available part numbers (2)

EFCG-10-500-11, EFCG-10-500-N-11

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EFCG-10-500-11EFCG-10 40ohm Flow Control +Check (E), 500L/min, N-opt: none | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 550 L/min | Pressure-comp. Adjustment Screw: None | Rated Current: 700 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 7% | Drive: Current input (use with dedicated power amplifier) | Mass: 51 kg | Design No.: 11
EFCG-10-500-N-11EFCG-10 40ohm Flow Control +Check (E), 500L/min, N-opt: N | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 550 L/min | Pressure-comp. Adjustment Screw: Pressure-compensation piston opening-adjustment screw (made to order — consult) | Rated Current: 700 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 7% | Drive: Current input (use with dedicated power amplifier) | Mass: 51 kg | Design No.: 11
