Yuken EFG-02 40Ω Proportional Flow Control Valve (E series, 20.6 MPa, size 02)

Yuken EFG-02 40Ω Proportional Flow Control Valve (E series, 20.6 MPa, size 02)

40Ω Series Proportional Electro-Hydraulic Flow Control Valves.

Key features

  • Suited to shock-free start/stop/speed-change of actuators
  • Use with a dedicated Yuken power amplifier
  • Sub-plate mounting, valve size 02
  • Max operating pressure 20.6 MPa, max adjustable flow 10 / 30 L/min, rated current 600 mA
  • Coil resistance 45Ω (40Ω series), hysteresis 5%
  • Optional pressure-compensation piston opening-adjustment screw (N)

Specifications

Type Proportional Flow Control Valve (E series, current-driven, 40Ω)
Series EFG
Mounting Sub-plate (G)
Valve Size 02
Max Pressure 20.6 MPa
Rated Current 600 mA
Coil 45Ω
Pressure/Temperature compensated Yes
Hysteresis 5%
Drive Current input (use with dedicated power amplifier)
Mass 8.2 kg
Design No. 31
EFG-02-10-31 EFG-02 40ohm Flow Control (E), 10L/min, N-opt: none | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 10 L/min | Flow Adj. Range: 0.3–10 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: None | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
EFG-02-10-N-31 EFG-02 40ohm Flow Control (E), 10L/min, N-opt: N | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 10 L/min | Flow Adj. Range: 0.3–10 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: Pressure-compensation piston opening-adjustment screw (made to order — consult) | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
EFG-02-30-31 EFG-02 40ohm Flow Control (E), 30L/min, N-opt: none | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 30 L/min | Flow Adj. Range: 0.3–30 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: None | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
EFG-02-30-N-31 EFG-02 40ohm Flow Control (E), 30L/min, N-opt: N | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 30 L/min | Flow Adj. Range: 0.3–30 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: Pressure-compensation piston opening-adjustment screw (made to order — consult) | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
Proportional Flow ControlYuken
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EFG-02 40Ω Proportional Flow Control Valve (E series, 20.6 MPa, size 02)

Brand Yuken·Proportional Flow Control

Available part numbers (4)

EFG-02-10-31, EFG-02-10-N-31, EFG-02-30-31, EFG-02-30-N-31

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EFG-02-10-31EFG-02 40ohm Flow Control (E), 10L/min, N-opt: none | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 10 L/min | Flow Adj. Range: 0.3–10 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: None | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
EFG-02-10-N-31EFG-02 40ohm Flow Control (E), 10L/min, N-opt: N | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 10 L/min | Flow Adj. Range: 0.3–10 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: Pressure-compensation piston opening-adjustment screw (made to order — consult) | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
EFG-02-30-31EFG-02 40ohm Flow Control (E), 30L/min, N-opt: none | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 30 L/min | Flow Adj. Range: 0.3–30 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: None | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
EFG-02-30-N-31EFG-02 40ohm Flow Control (E), 30L/min, N-opt: N | Type: Proportional Flow Control Valve (E series, current-driven, 40Ω) | Series: EFG | Mounting: Sub-plate (G) | Valve Size: 02 | Max Adjustable Flow: 30 L/min | Flow Adj. Range: 0.3–30 L/min | Max Pressure: 20.6 MPa | Pressure-comp. Adjustment Screw: Pressure-compensation piston opening-adjustment screw (made to order — consult) | Rated Current: 600 mA | Coil: 45Ω | Pressure/Temperature compensated: Yes | Hysteresis: 5% | Drive: Current input (use with dedicated power amplifier) | Mass: 8.2 kg | Design No.: 31
