Yuken EHDFG-01 Proportional Directional & Flow Control Valve (25 MPa, rated 30 L/min, size 01)

Yuken EHDFG-01 Proportional Directional & Flow Control Valve (25 MPa, rated 30 L/min, size 01)

Proportional Electro-Hydraulic Directional and Flow Control Valves.

Key features

  • Combines speed (flow) control and directional control in a single valve, so that an actuator's speed and direction can both be handled without a separate directional valve, simplifying the hydraulic circuit and reducing cost
  • Sub-plate mounting, valve size 01
  • Max operating pressure 25 MPa, tank port pressure 7 MPa, rated flow 30 L/min at 6.7 MPa valve pressure drop
  • Spool forms 3C2 and 3C40; meter-in (Y), meter-out (X) and meter-in/out (XY) control
  • Coil 10.5Ω, supply DC24V (40 W max)

Specifications

Type Proportional Directional & Flow Control Valve
Series EHDFG
Mounting Sub-plate (G)
Valve Size 01
Rated Flow 30 L/min (@6.7 MPa drop)
Max Pressure 25 MPa
Tank Port Pressure 7 MPa
Coil 10.5Ω, DC24V
Design No. 30
EHDFG-01-30-3C2-XY-30 EHDFG-01 Directional&Flow, 3C2, Meter-in / Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C2 | Control Direction: Meter-in / Meter-out control (XY) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C2-X-30 EHDFG-01 Directional&Flow, 3C2, Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C2 | Control Direction: Meter-out control (X) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C2-Y-30 EHDFG-01 Directional&Flow, 3C2, Meter-in control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C2 | Control Direction: Meter-in control (Y) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C40-XY-30 EHDFG-01 Directional&Flow, 3C40, Meter-in / Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C40 | Control Direction: Meter-in / Meter-out control (XY) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C40-X-30 EHDFG-01 Directional&Flow, 3C40, Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C40 | Control Direction: Meter-out control (X) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C40-Y-30 EHDFG-01 Directional&Flow, 3C40, Meter-in control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C40 | Control Direction: Meter-in control (Y) | Coil: 10.5Ω, DC24V | Design No.: 30
Proportional Directional & FlowYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EHDFG-01 Proportional Directional & Flow Control Valve (25 MPa, rated 30 L/min, size 01)

Brand Yuken·Proportional Directional & Flow

Available part numbers (6)

EHDFG-01-30-3C2-XY-30, EHDFG-01-30-3C2-X-30, EHDFG-01-30-3C2-Y-30, EHDFG-01-30-3C40-XY-30, EHDFG-01-30-3C40-X-30, EHDFG-01-30-3C40-Y-30

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EHDFG-01-30-3C2-XY-30EHDFG-01 Directional&Flow, 3C2, Meter-in / Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C2 | Control Direction: Meter-in / Meter-out control (XY) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C2-X-30EHDFG-01 Directional&Flow, 3C2, Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C2 | Control Direction: Meter-out control (X) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C2-Y-30EHDFG-01 Directional&Flow, 3C2, Meter-in control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C2 | Control Direction: Meter-in control (Y) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C40-XY-30EHDFG-01 Directional&Flow, 3C40, Meter-in / Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C40 | Control Direction: Meter-in / Meter-out control (XY) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C40-X-30EHDFG-01 Directional&Flow, 3C40, Meter-out control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C40 | Control Direction: Meter-out control (X) | Coil: 10.5Ω, DC24V | Design No.: 30
EHDFG-01-30-3C40-Y-30EHDFG-01 Directional&Flow, 3C40, Meter-in control, rated 30L/min | Type: Proportional Directional & Flow Control Valve | Series: EHDFG | Mounting: Sub-plate (G) | Valve Size: 01 | Rated Flow: 30 L/min (@6.7 MPa drop) | Max Pressure: 25 MPa | Tank Port Pressure: 7 MPa | Spool Form: 3C40 | Control Direction: Meter-in control (Y) | Coil: 10.5Ω, DC24V | Design No.: 30
