Yuken EHFBG-03-250 High-Flow Proportional Power-Saving Valve (24.5 MPa, max 250 L/min)

Yuken EHFBG-03-250 High-Flow Proportional Power-Saving Valve (24.5 MPa, max 250 L/min)

High Flow Series Proportional Electro-Hydraulic Flow Control and Relief Valves.

Key features

  • High-flow version of the EHFBG power-saving valve with roughly double the max flow of the standard series (03: 125→250, 06: 250→500 L/min) and a one-step smaller valve size for a more compact installation
  • Supplies only the minimum pressure and flow needed to drive the actuator, with temperature-compensated meter-in flow control
  • Sub-plate mounting, valve size 03
  • Max operating pressure 24.5 MPa, max flow 250 L/min
  • Pilot-relief pressure range C: 1.6–15.7 MPa / H: 1.8–24.5 MPa
  • With/without pilot relief, internal/external flow pilot, optional pressure sensor

Specifications

Type High-Flow Proportional Power-Saving Valve (Flow Control + Relief)
Series EHFBG (High Flow)
Mounting Sub-plate (G)
Valve Size 03
Max Adjustable Flow 250 L/min
Flow Adj. Range 2.5–250 L/min
Valve Pressure Drop 0.8 MPa
Max Pressure 24.5 MPa
Coil 10Ω, DC24V
Design No. 50
EHFBG-03-250-50 EHFBG-03-250 High-Flow Power-Saving, no pilot relief valve (flow control only), Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: None (no pilot relief valve) | Flow-control Pilot: Internal pilot | Pressure-control: None | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-E-50 EHFBG-03-250 High-Flow Power-Saving, no pilot relief valve (flow control only), External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: None (no pilot relief valve) | Flow-control Pilot: External pilot | Pressure-control: None | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-E-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-S-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop + sensor, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-E-S-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop + sensor, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-E-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-S-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop + sensor, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-E-S-50 EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop + sensor, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
Proportional Power SavingYuken
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EHFBG-03-250 High-Flow Proportional Power-Saving Valve (24.5 MPa, max 250 L/min)

Brand Yuken·Proportional Power Saving

Available part numbers (10)

EHFBG-03-250-50, EHFBG-03-250-E-50, EHFBG-03-250-C-50, EHFBG-03-250-C-E-50, EHFBG-03-250-C-S-50, EHFBG-03-250-C-E-S-50, EHFBG-03-250-H-50, EHFBG-03-250-H-E-50, EHFBG-03-250-H-S-50, EHFBG-03-250-H-E-S-50

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EHFBG-03-250-50EHFBG-03-250 High-Flow Power-Saving, no pilot relief valve (flow control only), Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: None (no pilot relief valve) | Flow-control Pilot: Internal pilot | Pressure-control: None | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-E-50EHFBG-03-250 High-Flow Power-Saving, no pilot relief valve (flow control only), External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: None (no pilot relief valve) | Flow-control Pilot: External pilot | Pressure-control: None | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-50EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-E-50EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-S-50EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop + sensor, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-C-E-S-50EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop + sensor, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-50EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-E-50EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-S-50EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop + sensor, Internal pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
EHFBG-03-250-H-E-S-50EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop + sensor, External pilot | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50
