Yuken EHFCG-06 Proportional Flow Control Valve with built-in check valve (24.5 MPa, size 06)

Yuken EHFCG-06 Proportional Flow Control Valve with built-in check valve (24.5 MPa, size 06)

Proportional Electro-Hydraulic Flow Control (and Check) Valves.

Key features

  • Remotely controls system flow proportionally to the input voltage; pressure- and temperature-compensated so the set flow is unaffected by load pressure or oil temperature . Built-in check valve
  • Sub-plate mounting, valve size 06
  • Max operating pressure 24.5 MPa, max adjustable flow 250 L/min, min adjustable flow 2.5 L/min
  • Internal- and external-pilot (E) versions
  • Coil resistance 10Ω, supply DC24V (28W max)

Specifications

Type Proportional Flow Control Valve with built-in Check
Series EHFCG
Mounting Sub-plate (G)
Valve Size 06
Max Adjustable Flow 250 L/min
Min Adjustable Flow 2.5 L/min
Max Pressure 24.5 MPa
Free Flow (check) 280 L/min
Pressure/Temperature compensated Yes
Coil 10Ω, DC24V
Design No. 50
EHFCG-06-250-50 EHFCG-06 Flow Control +Check, 250L/min, Internal pilot | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Adjustable Flow: 250 L/min | Min Adjustable Flow: 2.5 L/min | Max Pressure: 24.5 MPa | Free Flow (check): 280 L/min | Pilot: Internal pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50
EHFCG-06-250-E-50 EHFCG-06 Flow Control +Check, 250L/min, External pilot | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Adjustable Flow: 250 L/min | Min Adjustable Flow: 2.5 L/min | Max Pressure: 24.5 MPa | Free Flow (check): 280 L/min | Pilot: External pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50
Proportional Flow ControlYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken EHFCG-06 Proportional Flow Control Valve with built-in check valve (24.5 MPa, size 06)

Brand Yuken·Proportional Flow Control

Available part numbers (2)

EHFCG-06-250-50, EHFCG-06-250-E-50

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
EHFCG-06-250-50EHFCG-06 Flow Control +Check, 250L/min, Internal pilot | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Adjustable Flow: 250 L/min | Min Adjustable Flow: 2.5 L/min | Max Pressure: 24.5 MPa | Free Flow (check): 280 L/min | Pilot: Internal pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50
EHFCG-06-250-E-50EHFCG-06 Flow Control +Check, 250L/min, External pilot | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Adjustable Flow: 250 L/min | Min Adjustable Flow: 2.5 L/min | Max Pressure: 24.5 MPa | Free Flow (check): 280 L/min | Pilot: External pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50
