Yuken ERBG-06 Proportional Relieving & Reducing Valve (E series, 24.5 MPa, max 100 L/min, size 06)

Yuken ERBG-06 Proportional Relieving & Reducing Valve (E series, 24.5 MPa, max 100 L/min, size 06)

Proportional Electro-Hydraulic Relieving and Reducing Valves.

Key features

  • Use together with a dedicated Yuken power amplifier
  • Sub-plate mounting, valve size 06
  • Max operating pressure 24.5 MPa, max flow 100 L/min, max relief flow 35 L/min
  • Secondary pressure adjustment range B: 0.8–6.9 MPa / C: 1.2–13.7 MPa / H: 1.5–20.6 MPa
  • Coil resistance 10Ω, hysteresis 3%

Specifications

Type Proportional Relieving and Reducing Valve (E series, current-driven)
Series ERBG
Mounting Sub-plate (G)
Valve Size 06
Max Flow 100 L/min
Max Relief Flow 35 L/min
Coil 10Ω
Drive Current input (use with dedicated power amplifier)
Mass 12 kg
Design No. 51
ERBG-06-B-51 ERBG-06 Relieving/Reducing (E), B 0.8–6.9 MPa, max 100 L/min | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Flow: 100 L/min | Max Relief Flow: 35 L/min | Secondary Pressure Adj. Range: B (0.8–6.9 MPa) | Max Pressure: 6.9 MPa | Rated Current: 800 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 12 kg | Design No.: 51
ERBG-06-C-51 ERBG-06 Relieving/Reducing (E), C 1.2–13.7 MPa, max 100 L/min | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Flow: 100 L/min | Max Relief Flow: 35 L/min | Secondary Pressure Adj. Range: C (1.2–13.7 MPa) | Max Pressure: 13.7 MPa | Rated Current: 800 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 12 kg | Design No.: 51
ERBG-06-H-51 ERBG-06 Relieving/Reducing (E), H 1.5–20.6 MPa, max 100 L/min | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Flow: 100 L/min | Max Relief Flow: 35 L/min | Secondary Pressure Adj. Range: H (1.5–20.6 MPa) | Max Pressure: 20.6 MPa | Rated Current: 950 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 12 kg | Design No.: 51
Proportional Pressure ReducingYuken
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken ERBG-06 Proportional Relieving & Reducing Valve (E series, 24.5 MPa, max 100 L/min, size 06)

Brand Yuken·Proportional Pressure Reducing

Available part numbers (3)

ERBG-06-B-51, ERBG-06-C-51, ERBG-06-H-51

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ERBG-06-B-51ERBG-06 Relieving/Reducing (E), B 0.8–6.9 MPa, max 100 L/min | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Flow: 100 L/min | Max Relief Flow: 35 L/min | Secondary Pressure Adj. Range: B (0.8–6.9 MPa) | Max Pressure: 6.9 MPa | Rated Current: 800 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 12 kg | Design No.: 51
ERBG-06-C-51ERBG-06 Relieving/Reducing (E), C 1.2–13.7 MPa, max 100 L/min | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Flow: 100 L/min | Max Relief Flow: 35 L/min | Secondary Pressure Adj. Range: C (1.2–13.7 MPa) | Max Pressure: 13.7 MPa | Rated Current: 800 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 12 kg | Design No.: 51
ERBG-06-H-51ERBG-06 Relieving/Reducing (E), H 1.5–20.6 MPa, max 100 L/min | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 06 | Max Flow: 100 L/min | Max Relief Flow: 35 L/min | Secondary Pressure Adj. Range: H (1.5–20.6 MPa) | Max Pressure: 20.6 MPa | Rated Current: 950 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 12 kg | Design No.: 51
