Yuken Feed Control Valve 1-stage (UCF1G)

Yuken Feed Control Valve 1-stage (UCF1G)

Feed Control Valves.

Key features

  • Compact combination of flow control + check valve and deceleration valve for machine-tool rapid→feed switching by cam
  • Pressure/temperature compensated
  • Max. operating pressure: 14 MPa. 1-stage control type
  • Sizes 01/03/04
  • Deceleration valve max. flow A:12 / B:8 / C:4 L/min (size 01)
  • Internal / external (-E) drain

Specifications

Type Feed Control Valve (1-stage)
Mounting Gasket
Max. Operating Pressure 14 MPa
UCF1G-01-4-A-11 Feed Control Valve UCF1G-01-4-A-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 16 (12 at ≥7 MPa) L/min | Adjustment Range: 0.03–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-A-E-11 Feed Control Valve UCF1G-01-4-A-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 16 (12 at ≥7 MPa) L/min | Adjustment Range: 0.03–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-B-11 Feed Control Valve UCF1G-01-4-B-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 12 (8) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-B-E-11 Feed Control Valve UCF1G-01-4-B-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 12 (8) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-C-11 Feed Control Valve UCF1G-01-4-C-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 8 (4) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-C-E-11 Feed Control Valve UCF1G-01-4-C-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 8 (4) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-A-11 Feed Control Valve UCF1G-01-8-A-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 20 (12) L/min | Adjustment Range: 0.03–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-A-E-11 Feed Control Valve UCF1G-01-8-A-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 20 (12) L/min | Adjustment Range: 0.03–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-B-11 Feed Control Valve UCF1G-01-8-B-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 16 (8) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-B-E-11 Feed Control Valve UCF1G-01-8-B-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 16 (8) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-C-11 Feed Control Valve UCF1G-01-8-C-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 12 (4) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-C-E-11 Feed Control Valve UCF1G-01-8-C-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 12 (4) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-03-4-10 Feed Control Valve UCF1G-03-4-10, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 40 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 2.6 kg | Design No.: 10
UCF1G-03-8-10 Feed Control Valve UCF1G-03-8-10, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 40 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 2.6 kg | Design No.: 10
UCF1G-04-30-30 Feed Control Valve UCF1G-04-30-30, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 04 | Adjustable Flow: 30 L/min | Max. Flow: 80 (40) L/min | Adjustment Range: 0.1–22 L/min | Free Flow: 80 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 6.5 kg | Design No.: 30
Feed Control ValvesYuken
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken Feed Control Valve 1-stage (UCF1G)

Brand Yuken·Feed Control Valves

Available part numbers (15)

UCF1G-01-4-A-11, UCF1G-01-4-A-E-11, UCF1G-01-4-B-11, UCF1G-01-4-B-E-11, UCF1G-01-4-C-11, UCF1G-01-4-C-E-11, UCF1G-01-8-A-11, UCF1G-01-8-A-E-11, UCF1G-01-8-B-11, UCF1G-01-8-B-E-11 + 5 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCF1G-01-4-A-11Feed Control Valve UCF1G-01-4-A-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 16 (12 at ≥7 MPa) L/min | Adjustment Range: 0.03–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-A-E-11Feed Control Valve UCF1G-01-4-A-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 16 (12 at ≥7 MPa) L/min | Adjustment Range: 0.03–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-B-11Feed Control Valve UCF1G-01-4-B-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 12 (8) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-B-E-11Feed Control Valve UCF1G-01-4-B-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 12 (8) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-C-11Feed Control Valve UCF1G-01-4-C-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 8 (4) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-4-C-E-11Feed Control Valve UCF1G-01-4-C-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 8 (4) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-A-11Feed Control Valve UCF1G-01-8-A-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 20 (12) L/min | Adjustment Range: 0.03–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-A-E-11Feed Control Valve UCF1G-01-8-A-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 20 (12) L/min | Adjustment Range: 0.03–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-B-11Feed Control Valve UCF1G-01-8-B-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 16 (8) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-B-E-11Feed Control Valve UCF1G-01-8-B-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 16 (8) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-C-11Feed Control Valve UCF1G-01-8-C-11, internal drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 12 (4) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-01-8-C-E-11Feed Control Valve UCF1G-01-8-C-E-11, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 12 (4) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11
UCF1G-03-4-10Feed Control Valve UCF1G-03-4-10, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 40 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 2.6 kg | Design No.: 10
UCF1G-03-8-10Feed Control Valve UCF1G-03-8-10, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 40 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 2.6 kg | Design No.: 10
UCF1G-04-30-30Feed Control Valve UCF1G-04-30-30, external drain | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 04 | Adjustable Flow: 30 L/min | Max. Flow: 80 (40) L/min | Adjustment Range: 0.1–22 L/min | Free Flow: 80 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 6.5 kg | Design No.: 30
