Yuken Feed Control Valve 2-stage (UCF2G)

Yuken Feed Control Valve 2-stage (UCF2G)

Feed Control Valves.

Key features

  • Compact combination of flow control + check valve and deceleration valve for machine-tool rapid→feed switching by cam
  • Pressure/temperature compensated
  • Max. operating pressure: 14 MPa. 2-stage control type
  • Sizes 03/04
  • Internal / external (-E) drain

Specifications

Type Feed Control Valve (2-stage)
Mounting Gasket
Max. Operating Pressure 14 MPa
UCF2G-03-4-10 Feed Control Valve UCF2G-03-4-10, internal drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–4 L/min | Adjustment Range 2nd Stage: 0.05–4 L/min | Free Flow: 40 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-03-4-E-10 Feed Control Valve UCF2G-03-4-E-10, external drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–4 L/min | Adjustment Range 2nd Stage: 0.05–4 L/min | Free Flow: 40 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-03-8-10 Feed Control Valve UCF2G-03-8-10, internal drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–8 L/min | Adjustment Range 2nd Stage: 0.05–8 L/min | Free Flow: 40 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-03-8-E-10 Feed Control Valve UCF2G-03-8-E-10, external drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–8 L/min | Adjustment Range 2nd Stage: 0.05–8 L/min | Free Flow: 40 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-04-30-30 Feed Control Valve UCF2G-04-30-30, external drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 04 | Adjustable Flow: 30 L/min | Max. Flow: 80 (40) L/min | Adjustment Range 1st Stage: 0.1–22 L/min | Adjustment Range 2nd Stage: 0.1–17 L/min | Free Flow: 80 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 9.2 kg | Design No.: 30
Feed Control ValvesYuken
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken Feed Control Valve 2-stage (UCF2G)

Brand Yuken·Feed Control Valves

Available part numbers (5)

UCF2G-03-4-10, UCF2G-03-4-E-10, UCF2G-03-8-10, UCF2G-03-8-E-10, UCF2G-04-30-30

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCF2G-03-4-10Feed Control Valve UCF2G-03-4-10, internal drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–4 L/min | Adjustment Range 2nd Stage: 0.05–4 L/min | Free Flow: 40 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-03-4-E-10Feed Control Valve UCF2G-03-4-E-10, external drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–4 L/min | Adjustment Range 2nd Stage: 0.05–4 L/min | Free Flow: 40 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-03-8-10Feed Control Valve UCF2G-03-8-10, internal drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–8 L/min | Adjustment Range 2nd Stage: 0.05–8 L/min | Free Flow: 40 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-03-8-E-10Feed Control Valve UCF2G-03-8-E-10, external drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range 1st Stage: 0.1–8 L/min | Adjustment Range 2nd Stage: 0.05–8 L/min | Free Flow: 40 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 2.7 kg | Design No.: 10
UCF2G-04-30-30Feed Control Valve UCF2G-04-30-30, external drain | Type: Feed Control Valve (2-stage) | Mounting: Gasket | Valve Size: 04 | Adjustable Flow: 30 L/min | Max. Flow: 80 (40) L/min | Adjustment Range 1st Stage: 0.1–22 L/min | Adjustment Range 2nd Stage: 0.1–17 L/min | Free Flow: 80 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 9.2 kg | Design No.: 30
