Yuken Flow Control Valve (FG)

Yuken Flow Control Valve (FG)

Flow Control Valves · Flow Control and Check Valves.

Key features

  • Max. operating pressure: 14 MPa (size 01) / 21 MPa (02–10)
  • Max. adjustable flow: 4/8 (01) / 30 (02) / 125 (03) / 250 (06) / 500 (10) L/min
  • Digital scale (except size 01)
  • Pressure-compensated piston opening adjustment (-N) available

Specifications

Type Flow Control Valve
Mounting Sub-plate
Check Valve No
FG-01-4-11 Flow Control Valve FG-01-4 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-01-4-N-11 Flow Control Valve FG-01-4-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-01-8-11 Flow Control Valve FG-01-8 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-01-8-N-11 Flow Control Valve FG-01-8-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-02-30-30 Flow Control Valve FG-02-30 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30
FG-02-30-N-30 Flow Control Valve FG-02-30-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30
FG-03-125-30 Flow Control Valve FG-03-125 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30
FG-03-125-N-30 Flow Control Valve FG-03-125-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30
FG-06-250-30 Flow Control Valve FG-06-250 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30
FG-06-250-N-30 Flow Control Valve FG-06-250-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30
FG-10-500-30 Flow Control Valve FG-10-500 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30
FG-10-500-N-30 Flow Control Valve FG-10-500-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30
Flow Control & Pilot OperatedYuken
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken Flow Control Valve (FG)

Brand Yuken·Flow Control & Pilot Operated

Available part numbers (12)

FG-01-4-11, FG-01-4-N-11, FG-01-8-11, FG-01-8-N-11, FG-02-30-30, FG-02-30-N-30, FG-03-125-30, FG-03-125-N-30, FG-06-250-30, FG-06-250-N-30 + 2 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FG-01-4-11Flow Control Valve FG-01-4 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-01-4-N-11Flow Control Valve FG-01-4-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-01-8-11Flow Control Valve FG-01-8 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-01-8-N-11Flow Control Valve FG-01-8-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11
FG-02-30-30Flow Control Valve FG-02-30 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30
FG-02-30-N-30Flow Control Valve FG-02-30-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30
FG-03-125-30Flow Control Valve FG-03-125 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30
FG-03-125-N-30Flow Control Valve FG-03-125-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30
FG-06-250-30Flow Control Valve FG-06-250 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30
FG-06-250-N-30Flow Control Valve FG-06-250-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30
FG-10-500-30Flow Control Valve FG-10-500 | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30
FG-10-500-N-30Flow Control Valve FG-10-500-N | Type: Flow Control Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: No | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30
