Yuken H Type Pressure Control Valve (HG-06)

Yuken H Type Pressure Control Valve (HG-06)

H/HC Type Pressure Control Valves.

Key features

  • Max. operating pressure: 21 MPa
  • Max. flow: 125 L/min
  • H type, Sub-plate mounting
  • Pressure ranges: L/M/N/A/B/C (0.25–14 MPa)
  • Valve forms 1–4
  • Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table)

Specifications

Type H Type Pressure Control Valve
Mounting Sub-plate
Valve Size 06
Max. Operating Pressure 21 MPa
Max. Flow 125 L/min
Mass 6.1 kg
Design No. 22
HG-06-L1-22 H Type Pressure Control Valve HG-06-L1, Low Pressure Relief Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M1-22 H Type Pressure Control Valve HG-06-M1, Low Pressure Relief Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-L2-22 H Type Pressure Control Valve HG-06-L2, Sequence Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M2-22 H Type Pressure Control Valve HG-06-M2, Sequence Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N2-22 H Type Pressure Control Valve HG-06-N2, Sequence Valve, range N | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N2-P-22 H Type Pressure Control Valve HG-06-N2-P, Sequence Valve, range N, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A2-22 H Type Pressure Control Valve HG-06-A2, Sequence Valve, range A | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A2-P-22 H Type Pressure Control Valve HG-06-A2-P, Sequence Valve, range A, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B2-22 H Type Pressure Control Valve HG-06-B2, Sequence Valve, range B | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B2-P-22 H Type Pressure Control Valve HG-06-B2-P, Sequence Valve, range B, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C2-22 H Type Pressure Control Valve HG-06-C2, Sequence Valve, range C | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C2-P-22 H Type Pressure Control Valve HG-06-C2-P, Sequence Valve, range C, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-L3-22 H Type Pressure Control Valve HG-06-L3, Sequence Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M3-22 H Type Pressure Control Valve HG-06-M3, Sequence Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N3-22 H Type Pressure Control Valve HG-06-N3, Sequence Valve, range N | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N3-P-22 H Type Pressure Control Valve HG-06-N3-P, Sequence Valve, range N, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A3-22 H Type Pressure Control Valve HG-06-A3, Sequence Valve, range A | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A3-P-22 H Type Pressure Control Valve HG-06-A3-P, Sequence Valve, range A, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B3-22 H Type Pressure Control Valve HG-06-B3, Sequence Valve, range B | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B3-P-22 H Type Pressure Control Valve HG-06-B3-P, Sequence Valve, range B, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C3-22 H Type Pressure Control Valve HG-06-C3, Sequence Valve, range C | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C3-P-22 H Type Pressure Control Valve HG-06-C3-P, Sequence Valve, range C, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-L4-22 H Type Pressure Control Valve HG-06-L4, Unloading Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M4-22 H Type Pressure Control Valve HG-06-M4, Unloading Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N4-22 H Type Pressure Control Valve HG-06-N4, Unloading Valve, range N | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N4-P-22 H Type Pressure Control Valve HG-06-N4-P, Unloading Valve, range N, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A4-22 H Type Pressure Control Valve HG-06-A4, Unloading Valve, range A | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A4-P-22 H Type Pressure Control Valve HG-06-A4-P, Unloading Valve, range A, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B4-22 H Type Pressure Control Valve HG-06-B4, Unloading Valve, range B | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B4-P-22 H Type Pressure Control Valve HG-06-B4-P, Unloading Valve, range B, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C4-22 H Type Pressure Control Valve HG-06-C4, Unloading Valve, range C | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C4-P-22 H Type Pressure Control Valve HG-06-C4-P, Unloading Valve, range C, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
Pressure Control (H/HC)Yuken
32 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken H Type Pressure Control Valve (HG-06)

Brand Yuken·Pressure Control (H/HC)

Available part numbers (32)

HG-06-L1-22, HG-06-M1-22, HG-06-L2-22, HG-06-M2-22, HG-06-N2-22, HG-06-N2-P-22, HG-06-A2-22, HG-06-A2-P-22, HG-06-B2-22, HG-06-B2-P-22 + 22 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HG-06-L1-22H Type Pressure Control Valve HG-06-L1, Low Pressure Relief Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M1-22H Type Pressure Control Valve HG-06-M1, Low Pressure Relief Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Low Pressure Relief Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-L2-22H Type Pressure Control Valve HG-06-L2, Sequence Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M2-22H Type Pressure Control Valve HG-06-M2, Sequence Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N2-22H Type Pressure Control Valve HG-06-N2, Sequence Valve, range N | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N2-P-22H Type Pressure Control Valve HG-06-N2-P, Sequence Valve, range N, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A2-22H Type Pressure Control Valve HG-06-A2, Sequence Valve, range A | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A2-P-22H Type Pressure Control Valve HG-06-A2-P, Sequence Valve, range A, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B2-22H Type Pressure Control Valve HG-06-B2, Sequence Valve, range B | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B2-P-22H Type Pressure Control Valve HG-06-B2-P, Sequence Valve, range B, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C2-22H Type Pressure Control Valve HG-06-C2, Sequence Valve, range C | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C2-P-22H Type Pressure Control Valve HG-06-C2-P, Sequence Valve, range C, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-L3-22H Type Pressure Control Valve HG-06-L3, Sequence Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M3-22H Type Pressure Control Valve HG-06-M3, Sequence Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N3-22H Type Pressure Control Valve HG-06-N3, Sequence Valve, range N | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N3-P-22H Type Pressure Control Valve HG-06-N3-P, Sequence Valve, range N, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A3-22H Type Pressure Control Valve HG-06-A3, Sequence Valve, range A | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A3-P-22H Type Pressure Control Valve HG-06-A3-P, Sequence Valve, range A, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B3-22H Type Pressure Control Valve HG-06-B3, Sequence Valve, range B | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B3-P-22H Type Pressure Control Valve HG-06-B3-P, Sequence Valve, range B, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C3-22H Type Pressure Control Valve HG-06-C3, Sequence Valve, range C | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C3-P-22H Type Pressure Control Valve HG-06-C3-P, Sequence Valve, range C, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-L4-22H Type Pressure Control Valve HG-06-L4, Unloading Valve, range L | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-M4-22H Type Pressure Control Valve HG-06-M4, Unloading Valve, range M | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N4-22H Type Pressure Control Valve HG-06-N4, Unloading Valve, range N | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-N4-P-22H Type Pressure Control Valve HG-06-N4-P, Unloading Valve, range N, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A4-22H Type Pressure Control Valve HG-06-A4, Unloading Valve, range A | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-A4-P-22H Type Pressure Control Valve HG-06-A4-P, Unloading Valve, range A, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B4-22H Type Pressure Control Valve HG-06-B4, Unloading Valve, range B | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-B4-P-22H Type Pressure Control Valve HG-06-B4-P, Unloading Valve, range B, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C4-22H Type Pressure Control Valve HG-06-C4, Unloading Valve, range C | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
HG-06-C4-P-22H Type Pressure Control Valve HG-06-C4-P, Unloading Valve, range C, aux pilot | Type: H Type Pressure Control Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Unloading Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 6.1 kg | Design No.: 22
