Yuken — L-DSG-03 Energy-Saving Solenoid Operated Directional Valve

Yuken — L-DSG-03 Energy-Saving Solenoid Operated Directional Valve

3/8 Solenoid Operated Directional Valves, DSG-03 Series — Energy-saving type.

Key features

  • Max. operating pressure 16 MPa, max. flow 60 L/min, tank back pressure 16 MPa, max. switching frequency 240 min-1 (R solenoid) / 120 min-1
  • Detailed specifications by inquiry
  • Subplate mounting

Specifications

Type Energy-saving (Solenoid Operated)
Valve Size 03 (Rc 3/8)
Max Pressure 16 MPa
Max Flow 60 L/min
Tank Back Pressure 16 MPa
Max Switching Freq 240 (R) / 120 min-1
Mounting Subplate (ISO 4401)
Spool Selection Per base DSG model table (specify at RFQ)
Coil AC/DC/R (RFQ)
Wiring Per base series (RFQ)
Design No. 50
Note Energy-saving type — detailed spec by separate inquiry
L-DSG-03-3C*-*-50 L-DSG-03 solenoid directional valve, spool group 3C (3-position, spring centered) | Type: Energy-saving (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 16 MPa | Max Flow: 60 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 240 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 3Cx (spool no. per base table) | Spring: 3-position, spring centered | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 50 | Note: Energy-saving type — detailed spec by separate inquiry
L-DSG-03-2D2-*-50 L-DSG-03 solenoid directional valve, spool group 2D2 (2-position, no-spring detented) | Type: Energy-saving (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 16 MPa | Max Flow: 60 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 240 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2D2 | Spring: 2-position, no-spring detented | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 50 | Note: Energy-saving type — detailed spec by separate inquiry
L-DSG-03-2B*-*-50 L-DSG-03 solenoid directional valve, spool group 2B (2-position, spring offset) | Type: Energy-saving (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 16 MPa | Max Flow: 60 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 240 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2Bx (spool no. per base table) | Spring: 2-position, spring offset | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 50 | Note: Energy-saving type — detailed spec by separate inquiry
Solenoid OperatedYuken
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken — L-DSG-03 Energy-Saving Solenoid Operated Directional Valve

Brand Yuken·Solenoid Operated

Available part numbers (3)

L-DSG-03-3C*-*-50, L-DSG-03-2D2-*-50, L-DSG-03-2B*-*-50

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
L-DSG-03-3C*-*-50L-DSG-03 solenoid directional valve, spool group 3C (3-position, spring centered) | Type: Energy-saving (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 16 MPa | Max Flow: 60 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 240 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 3Cx (spool no. per base table) | Spring: 3-position, spring centered | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 50 | Note: Energy-saving type — detailed spec by separate inquiry
L-DSG-03-2D2-*-50L-DSG-03 solenoid directional valve, spool group 2D2 (2-position, no-spring detented) | Type: Energy-saving (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 16 MPa | Max Flow: 60 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 240 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2D2 | Spring: 2-position, no-spring detented | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 50 | Note: Energy-saving type — detailed spec by separate inquiry
L-DSG-03-2B*-*-50L-DSG-03 solenoid directional valve, spool group 2B (2-position, spring offset) | Type: Energy-saving (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 16 MPa | Max Flow: 60 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 240 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2Bx (spool no. per base table) | Spring: 2-position, spring offset | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 50 | Note: Energy-saving type — detailed spec by separate inquiry
