Yuken 'M' Series Electric Motor M4 (Coupling / separate housing, 5.5/7.5/11/15/18.5 kW x 4P)

Yuken 'M' Series Electric Motor M4 (Coupling / separate housing, 5.5/7.5/11/15/18.5 kW x 4P)

'M' Series Electric Motors (Type M4).

Key features

  • Coupling / separate housing mounting type for Yuken hydraulic pumps: A37 (single, excl. 04E), PV2R2 (vane, special design)
  • Output: 5.5/7.5/11/15/18.5 kW x 4P
  • Voltage: 50Hz AC200V / 60Hz AC200/220/230V
  • Insulation class F
  • Totally enclosed, surface-cooled (IP44 / IC411 / IEC60034-1)

Specifications

Motor Type M4
Mounting Coupling / separate housing
Insulation Class F
Enclosure Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1)
Ambient Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m
Applicable Pumps A37 (single, excl. 04E), PV2R2 (vane, special design)
Design No 40
M4-5.5-40 M Series motor M4, 5.5kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 5.5 kW x 4P | Electrical: 200V-50Hz: 23.4A rated / 200A start / 1465rpm; 200V-60Hz: 21.4A rated / 166A start / 1760rpm; 220V-60Hz: 20.6A rated / 183A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 65 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-7.5-40 M Series motor M4, 7.5kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 7.5 kW x 4P | Electrical: 200V-50Hz: 30.8A rated / 264A start / 1460rpm; 200V-60Hz: 28.6A rated / 218A start / 1755rpm; 220V-60Hz: 27.4A rated / 240A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 76 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-11-40 M Series motor M4, 11kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 11 kW x 4P | Electrical: 200V-50Hz: 46.0A rated / 365A start / 1475rpm; 200V-60Hz: 42.0A rated / 302A start / 1770rpm; 220V-60Hz: 40.0A rated / 332A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 114 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-15-40 M Series motor M4, 15kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 15 kW x 4P | Electrical: 200V-50Hz: 58.8A rated / 484A start / 1470rpm; 200V-60Hz: 55.6A rated / 408A start / 1760rpm; 220V-60Hz: 52.0A rated / 449A start / 1770rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 131 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-18.5-40 M Series motor M4, 18.5kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 18.5 kW x 4P | Electrical: 200V-50Hz: 74.0A rated / 668A start / 1475rpm; 200V-60Hz: 69.0A rated / 524A start / 1770rpm; 220V-60Hz: 65.0A rated / 576A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 193 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
MotorsYuken
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken 'M' Series Electric Motor M4 (Coupling / separate housing, 5.5/7.5/11/15/18.5 kW x 4P)

Brand Yuken·Motors

Available part numbers (5)

M4-5.5-40, M4-7.5-40, M4-11-40, M4-15-40, M4-18.5-40

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
M4-5.5-40M Series motor M4, 5.5kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 5.5 kW x 4P | Electrical: 200V-50Hz: 23.4A rated / 200A start / 1465rpm; 200V-60Hz: 21.4A rated / 166A start / 1760rpm; 220V-60Hz: 20.6A rated / 183A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 65 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-7.5-40M Series motor M4, 7.5kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 7.5 kW x 4P | Electrical: 200V-50Hz: 30.8A rated / 264A start / 1460rpm; 200V-60Hz: 28.6A rated / 218A start / 1755rpm; 220V-60Hz: 27.4A rated / 240A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 76 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-11-40M Series motor M4, 11kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 11 kW x 4P | Electrical: 200V-50Hz: 46.0A rated / 365A start / 1475rpm; 200V-60Hz: 42.0A rated / 302A start / 1770rpm; 220V-60Hz: 40.0A rated / 332A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 114 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-15-40M Series motor M4, 15kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 15 kW x 4P | Electrical: 200V-50Hz: 58.8A rated / 484A start / 1470rpm; 200V-60Hz: 55.6A rated / 408A start / 1760rpm; 220V-60Hz: 52.0A rated / 449A start / 1770rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 131 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
M4-18.5-40M Series motor M4, 18.5kW x 4P, Coupling / separate housing | Motor Type: M4 | Mounting: Coupling / separate housing | Output: 18.5 kW x 4P | Electrical: 200V-50Hz: 74.0A rated / 668A start / 1475rpm; 200V-60Hz: 69.0A rated / 524A start / 1770rpm; 220V-60Hz: 65.0A rated / 576A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 193 kg | Applicable Pumps: A37 (single, excl. 04E), PV2R2 (vane, special design) | Design No: 40
