Yuken 'M' Series Electric Motor M7 (Coupling / separate housing, 11/15 kW x 4P)

Yuken 'M' Series Electric Motor M7 (Coupling / separate housing, 11/15 kW x 4P)

'M' Series Electric Motors (Type M7).

Key features

  • Coupling / separate housing mounting type for Yuken hydraulic pumps: A3H37 (high-pressure piston pump)
  • Output: 11/15 kW x 4P
  • Voltage: 50Hz AC200V / 60Hz AC200/220/230V
  • Insulation class F
  • Totally enclosed, surface-cooled (IP44 / IC411 / IEC60034-1)

Specifications

Motor Type M7
Mounting Coupling / separate housing
Insulation Class F
Enclosure Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1)
Ambient Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m
Applicable Pumps A3H37 (high-pressure piston pump)
Design No 40
M7-11-40 M Series motor M7, 11kW x 4P, Coupling / separate housing | Motor Type: M7 | Mounting: Coupling / separate housing | Output: 11 kW x 4P | Electrical: 200V-50Hz: 46.0A rated / 365A start / 1475rpm; 200V-60Hz: 42.0A rated / 302A start / 1770rpm; 220V-60Hz: 40.0A rated / 332A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 114 kg | Applicable Pumps: A3H37 (high-pressure piston pump) | Design No: 40
M7-15-40 M Series motor M7, 15kW x 4P, Coupling / separate housing | Motor Type: M7 | Mounting: Coupling / separate housing | Output: 15 kW x 4P | Electrical: 200V-50Hz: 58.8A rated / 484A start / 1470rpm; 200V-60Hz: 55.6A rated / 408A start / 1760rpm; 220V-60Hz: 52.0A rated / 449A start / 1770rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 131 kg | Applicable Pumps: A3H37 (high-pressure piston pump) | Design No: 40
MotorsYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken 'M' Series Electric Motor M7 (Coupling / separate housing, 11/15 kW x 4P)

Brand Yuken·Motors

Available part numbers (2)

M7-11-40, M7-15-40

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
M7-11-40M Series motor M7, 11kW x 4P, Coupling / separate housing | Motor Type: M7 | Mounting: Coupling / separate housing | Output: 11 kW x 4P | Electrical: 200V-50Hz: 46.0A rated / 365A start / 1475rpm; 200V-60Hz: 42.0A rated / 302A start / 1770rpm; 220V-60Hz: 40.0A rated / 332A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 114 kg | Applicable Pumps: A3H37 (high-pressure piston pump) | Design No: 40
M7-15-40M Series motor M7, 15kW x 4P, Coupling / separate housing | Motor Type: M7 | Mounting: Coupling / separate housing | Output: 15 kW x 4P | Electrical: 200V-50Hz: 58.8A rated / 484A start / 1470rpm; 200V-60Hz: 55.6A rated / 408A start / 1760rpm; 220V-60Hz: 52.0A rated / 449A start / 1770rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 131 kg | Applicable Pumps: A3H37 (high-pressure piston pump) | Design No: 40
