Yuken PAL Pump PM10 Motor-Pump (Pressure Compensator Type, 0.75/1.5 kW x 4P)

Yuken PAL Pump PM10 Motor-Pump (Pressure Compensator Type, 0.75/1.5 kW x 4P)

PAL Pump, Pressure Compensator Type (PM series motor-pump).

Key features

  • Theoretical displacement: 10.0 cm3/rev
  • Min. adjustable flow: 2.0 cm3/rev
  • Pressure adjustment range: B 1.2-7 MPa / C 2-16 MPa
  • Motor: 0.75/1.5 kW x 4P, 50Hz AC200V / 60Hz AC200/220/230V
  • Control type: 01 (pressure compensator)

Specifications

Series PM10
Type Motor-Pump (variable piston pump + motor)
Control 01 Pressure Compensator
Theoretical Displacement 10.0 cm3/rev
Min Adjustable Flow 2.0 cm3/rev
Motor Voltage 50Hz AC200V / 60Hz AC200/220/230V
Design No 31
PM10-01B-0.75-31 PAL Pump PM10, 0.75kW, pressure range B (1.2~7 MPa) | Series: PM10 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 10.0 cm3/rev | Min Adjustable Flow: 2.0 cm3/rev | Pressure Range Code: B (1.2~7 MPa) | Max Working Pressure: 7 MPa | Motor Output: 0.75 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 28.1 kg | Design No: 31
PM10-01B-1.5-31 PAL Pump PM10, 1.5kW, pressure range B (1.2~7 MPa) | Series: PM10 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 10.0 cm3/rev | Min Adjustable Flow: 2.0 cm3/rev | Pressure Range Code: B (1.2~7 MPa) | Max Working Pressure: 7 MPa | Motor Output: 1.5 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 41.8 kg | Design No: 31
PM10-01C-1.5-31 PAL Pump PM10, 1.5kW, pressure range C (2~16 MPa) | Series: PM10 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 10.0 cm3/rev | Min Adjustable Flow: 2.0 cm3/rev | Pressure Range Code: C (2~16 MPa) | Max Working Pressure: 16 MPa | Motor Output: 1.5 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 41.8 kg | Design No: 31
Motor PumpsYuken
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken PAL Pump PM10 Motor-Pump (Pressure Compensator Type, 0.75/1.5 kW x 4P)

Brand Yuken·Motor Pumps

Available part numbers (3)

PM10-01B-0.75-31, PM10-01B-1.5-31, PM10-01C-1.5-31

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PM10-01B-0.75-31PAL Pump PM10, 0.75kW, pressure range B (1.2~7 MPa) | Series: PM10 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 10.0 cm3/rev | Min Adjustable Flow: 2.0 cm3/rev | Pressure Range Code: B (1.2~7 MPa) | Max Working Pressure: 7 MPa | Motor Output: 0.75 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 28.1 kg | Design No: 31
PM10-01B-1.5-31PAL Pump PM10, 1.5kW, pressure range B (1.2~7 MPa) | Series: PM10 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 10.0 cm3/rev | Min Adjustable Flow: 2.0 cm3/rev | Pressure Range Code: B (1.2~7 MPa) | Max Working Pressure: 7 MPa | Motor Output: 1.5 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 41.8 kg | Design No: 31
PM10-01C-1.5-31PAL Pump PM10, 1.5kW, pressure range C (2~16 MPa) | Series: PM10 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 10.0 cm3/rev | Min Adjustable Flow: 2.0 cm3/rev | Pressure Range Code: C (2~16 MPa) | Max Working Pressure: 16 MPa | Motor Output: 1.5 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 41.8 kg | Design No: 31
