• Yuken Pressure Reducing Valve (RG-03/06/10)
1 1

Yuken Pressure Reducing Valve (RG-03/06/10)

Yuken Pressure Reducing Valve (RG-03/06/10)

Pressure Reducing Valves · Pressure Reducing and Check Valves.

Key features

  • Max. operating pressure: 21 MPa
  • Pressure adjustment range: B (0.7–7) / C (3.5–14) / H (7–20.5) MPa
  • Max. flow up to 250 L/min (size 10)
  • Pressure Reducing Valve, Sub-plate mounting

Specifications

Type Pressure Reducing Valve
Mounting Sub-plate
Max. Operating Pressure 21 MPa
Check Valve No
RG-03-B-22 Pressure Reducing Valve RG-03-B, Sub-plate, range B | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No
RG-03-C-22 Pressure Reducing Valve RG-03-C, Sub-plate, range C | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No
RG-03-H-22 Pressure Reducing Valve RG-03-H, Sub-plate, range H | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No
RG-06-B-22 Pressure Reducing Valve RG-06-B, Sub-plate, range B | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No
RG-06-C-22 Pressure Reducing Valve RG-06-C, Sub-plate, range C | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No
RG-06-H-22 Pressure Reducing Valve RG-06-H, Sub-plate, range H | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No
RG-10-B-20 Pressure Reducing Valve RG-10-B, Sub-plate, range B | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No
RG-10-C-20 Pressure Reducing Valve RG-10-C, Sub-plate, range C | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No
RG-10-H-20 Pressure Reducing Valve RG-10-H, Sub-plate, range H | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No
Pressure Reducing ValvesYuken
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken Pressure Reducing Valve (RG-03/06/10)

Brand Yuken·Pressure Reducing Valves

Available part numbers (9)

RG-03-B-22, RG-03-C-22, RG-03-H-22, RG-06-B-22, RG-06-C-22, RG-06-H-22, RG-10-B-20, RG-10-C-20, RG-10-H-20

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
RG-03-B-22Pressure Reducing Valve RG-03-B, Sub-plate, range B | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No
RG-03-C-22Pressure Reducing Valve RG-03-C, Sub-plate, range C | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No
RG-03-H-22Pressure Reducing Valve RG-03-H, Sub-plate, range H | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No
RG-06-B-22Pressure Reducing Valve RG-06-B, Sub-plate, range B | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No
RG-06-C-22Pressure Reducing Valve RG-06-C, Sub-plate, range C | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No
RG-06-H-22Pressure Reducing Valve RG-06-H, Sub-plate, range H | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No
RG-10-B-20Pressure Reducing Valve RG-10-B, Sub-plate, range B | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No
RG-10-C-20Pressure Reducing Valve RG-10-C, Sub-plate, range C | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No
RG-10-H-20Pressure Reducing Valve RG-10-H, Sub-plate, range H | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No
