Yuken SB1110 Proportional Pressure Control Valve (3/8 sub-plate, max 30 L/min)

Yuken SB1110 Proportional Pressure Control Valve (3/8 sub-plate, max 30 L/min)

Proportional Electro-Hydraulic Pressure Control Valves.

Key features

  • Normally-open, closed-loop pressure control controlling system pressure proportionally to input voltage, stable even at low flow
  • Port 3/8, sub-plate mounting
  • Max flow 30 L/min
  • Pressure adjustment range: B (0.2–6.9 MPa), H (0.2–24.5 MPa)
  • Coil resistance 10Ω, supply DC24V
  • Hysteresis 1% max

Specifications

Type Proportional Pressure Control Valve
Series SB1110
Mounting Sub-plate
Port 3/8
Max Flow 30 L/min
Control Closed loop (normally open)
Coil 10Ω, DC24V
Hysteresis 1% max
Design No. 20
SB1110-B-20 SB1110 Proportional Pressure Control, B 0.2–6.9 MPa, 3/8, max 30 L/min | Type: Proportional Pressure Control Valve | Series: SB1110 | Mounting: Sub-plate | Port: 3/8 | Max Flow: 30 L/min | Pressure Adj. Range: B (0.2–6.9 MPa) | Max Pressure: 6.9 MPa | Control: Closed loop (normally open) | Coil: 10Ω, DC24V | Hysteresis: 1% max | Design No.: 20
SB1110-H-20 SB1110 Proportional Pressure Control, H 0.2–24.5 MPa, 3/8, max 30 L/min | Type: Proportional Pressure Control Valve | Series: SB1110 | Mounting: Sub-plate | Port: 3/8 | Max Flow: 30 L/min | Pressure Adj. Range: H (0.2–24.5 MPa) | Max Pressure: 24.5 MPa | Control: Closed loop (normally open) | Coil: 10Ω, DC24V | Hysteresis: 1% max | Design No.: 20
Proportional Pressure ControlYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken SB1110 Proportional Pressure Control Valve (3/8 sub-plate, max 30 L/min)

Brand Yuken·Proportional Pressure Control

Available part numbers (2)

SB1110-B-20, SB1110-H-20

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SB1110-B-20SB1110 Proportional Pressure Control, B 0.2–6.9 MPa, 3/8, max 30 L/min | Type: Proportional Pressure Control Valve | Series: SB1110 | Mounting: Sub-plate | Port: 3/8 | Max Flow: 30 L/min | Pressure Adj. Range: B (0.2–6.9 MPa) | Max Pressure: 6.9 MPa | Control: Closed loop (normally open) | Coil: 10Ω, DC24V | Hysteresis: 1% max | Design No.: 20
SB1110-H-20SB1110 Proportional Pressure Control, H 0.2–24.5 MPa, 3/8, max 30 L/min | Type: Proportional Pressure Control Valve | Series: SB1110 | Mounting: Sub-plate | Port: 3/8 | Max Flow: 30 L/min | Pressure Adj. Range: H (0.2–24.5 MPa) | Max Pressure: 24.5 MPa | Control: Closed loop (normally open) | Coil: 10Ω, DC24V | Hysteresis: 1% max | Design No.: 20
