Safety Controller
Autonics
[AUTONICS] SFC-R Series Safety Relay Controllers
Family ID: AUTONICS-SFC-R-SERIES
Safety relay controllers and expansion units with forced-guided relay contact output. Higher load current capacity than P-channel FET versions. SFC-ER expansion units extend output capacity of base SFC controllers. SFC-R standalone relay controllers in 2-output and 4-output configurations. SIL3, PLe, Category 4 certified. Screw and screwless terminal options.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| AUTONICS-SFC-ER412-T | — | AUTONICS | Safety relay unit | SFC Series | Expansion relay unit | 4 outputs | Forced-guided relay contact | 24 VDC | Screw terminal | IP20 | expansion for SFC controllers | ||
| AUTONICS-SFC-ER412-S | — | AUTONICS | Safety relay unit | SFC Series | Expansion relay unit | 4 outputs | Forced-guided relay contact | 24 VDC | Screwless terminal | IP20 | expansion for SFC controllers | ||
| AUTONICS-SFC-R412-T | — | AUTONICS | Safety relay unit | SFC Series | Relay safety controller | 4 outputs | Forced-guided relay contact | 24 VDC | Screw terminal | IP20 | relay output controller | ||
| AUTONICS-SFC-R412-S | — | AUTONICS | Safety relay unit | SFC Series | Relay safety controller | 4 outputs | Forced-guided relay contact | 24 VDC | Screwless terminal | IP20 | relay output controller | ||
| AUTONICS-SFC-R212-T | — | AUTONICS | Safety relay unit | SFC Series | Relay safety controller | 2 outputs | Forced-guided relay contact | 24 VDC | Screw terminal | IP20 | 2-output relay controller | ||
| AUTONICS-SFC-R212-S | — | AUTONICS | Safety relay unit | SFC Series | Relay safety controller | 2 outputs | Forced-guided relay contact | 24 VDC | Screwless terminal | IP20 | 2-output relay controller | ||
| AUTONICS-SFC-R212-R2T-T | — | AUTONICS | Safety relay unit | SFC Series | Relay safety controller dual | 2+2 outputs | Forced-guided relay contact | 24 VDC | Screw terminal | IP20 | dual 2-output relay | ||
| AUTONICS-SFC-R212-R2T-S | — | AUTONICS | Safety relay unit | SFC Series | Relay safety controller dual | 2+2 outputs | Forced-guided relay contact | 24 VDC | Screwless terminal | IP20 | dual 2-output relay |
