[GGM] — K35-3657 Series DC Planetary Geared Motor (ø35mm, 12/24V, 1/5–1/721)
Family ID: GGM-K35-3657
GGM K35-3657 DC planetary geared motor, ø35mm frame, ø6mm shaft, 4-M3 flange (PCD ø26). Two windings (12V/24V), 13 ratios 1/5 to 1/721; 218g.
26 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K35-0005-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/5, 1000 rpm / 1 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/5 | Output Speed (max eff.): 1000 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 22.1 mm | Type: DC planetary geared motor | ||
| K35-0014-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/14, 357 rpm / 2.2 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 357 rpm | Output Torque (max eff.): 2.2 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0019-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/19, 263 rpm / 3 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 263 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0027-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/27, 185 rpm / 4.2 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/27 | Output Speed (max eff.): 185 rpm | Output Torque (max eff.): 4.2 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0051-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/51, 98 rpm / 7.4 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/51 | Output Speed (max eff.): 98 rpm | Output Torque (max eff.): 7.4 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0071-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/71, 70 rpm / 10 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/71 | Output Speed (max eff.): 70 rpm | Output Torque (max eff.): 10 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0100-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/100, 50 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/100 | Output Speed (max eff.): 50 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0139-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/139, 35.9 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/139 | Output Speed (max eff.): 35.9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0189-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/189, 26.4 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/189 | Output Speed (max eff.): 26.4 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0264-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/264, 18.9 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/264 | Output Speed (max eff.): 18.9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0369-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/369, 13.5 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/369 | Output Speed (max eff.): 13.5 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0516-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/516, 9.6 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/516 | Output Speed (max eff.): 9.6 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0721-KD3657U1 | GGM K35-3657 DC 12V planetary geared motor, ratio 1/721, 6.9 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U1 | Voltage: DC 12V | Gear Ratio: 1/721 | Output Speed (max eff.): 6.9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0005-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/5, 1000 rpm / 1 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/5 | Output Speed (max eff.): 1000 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 22.1 mm | Type: DC planetary geared motor | ||
| K35-0014-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/14, 357 rpm / 2.2 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 357 rpm | Output Torque (max eff.): 2.2 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0019-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/19, 263 rpm / 3 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 263 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0027-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/27, 185 rpm / 4.2 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/27 | Output Speed (max eff.): 185 rpm | Output Torque (max eff.): 4.2 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor | ||
| K35-0051-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/51, 98 rpm / 7.4 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/51 | Output Speed (max eff.): 98 rpm | Output Torque (max eff.): 7.4 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0071-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/71, 70 rpm / 10 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/71 | Output Speed (max eff.): 70 rpm | Output Torque (max eff.): 10 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0100-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/100, 50 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/100 | Output Speed (max eff.): 50 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0139-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/139, 35.9 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/139 | Output Speed (max eff.): 35.9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor | ||
| K35-0189-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/189, 26.4 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/189 | Output Speed (max eff.): 26.4 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0264-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/264, 18.9 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/264 | Output Speed (max eff.): 18.9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0369-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/369, 13.5 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/369 | Output Speed (max eff.): 13.5 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0516-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/516, 9.6 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/516 | Output Speed (max eff.): 9.6 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor | ||
| K35-0721-KD3657U2 | GGM K35-3657 DC 24V planetary geared motor, ratio 1/721, 6.9 rpm / 12 kgf·cm @ max eff. | GGM | Motor: KD3657U2 | Voltage: DC 24V | Gear Ratio: 1/721 | Output Speed (max eff.): 6.9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 6000 rpm | Stall Torque: 1.6 kgf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor |
