[GGM] — K42-4266 Series DC Planetary Geared Motor (ø42mm, 12/24V, 1/4–1/3600)
DC GGM

[GGM] — K42-4266 Series DC Planetary Geared Motor (ø42mm, 12/24V, 1/4–1/3600)

Family ID: GGM-K42-4266

GGM K42-4266 DC planetary geared motor, ø42mm frame, ø8mm shaft, 4-M4 flange (PCD ø35). Two windings (12V/24V), 21 ratios 1/4 to 1/3600; 350g.

42 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K42-0004-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/4, 1470 rpm / 1.7 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/4 | Output Speed (max eff.): 1470 rpm | Output Torque (max eff.): 1.7 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 32.5 mm | Type: DC planetary geared motor
K42-0014-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/14, 420 rpm / 4.9 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 420 rpm | Output Torque (max eff.): 4.9 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: DC planetary geared motor
K42-0017-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/17, 346 rpm / 5.9 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/17 | Output Speed (max eff.): 346 rpm | Output Torque (max eff.): 5.9 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: DC planetary geared motor
K42-0024-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/24, 245 rpm / 8.4 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/24 | Output Speed (max eff.): 245 rpm | Output Torque (max eff.): 8.4 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: DC planetary geared motor
K42-0049-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/49, 120 rpm / 14 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/49 | Output Speed (max eff.): 120 rpm | Output Torque (max eff.): 14 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0061-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/61, 96 rpm / 17 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/61 | Output Speed (max eff.): 96 rpm | Output Torque (max eff.): 17 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0084-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/84, 70 rpm / 24 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/84 | Output Speed (max eff.): 70 rpm | Output Torque (max eff.): 24 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0104-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/104, 57 rpm / 29 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/104 | Output Speed (max eff.): 57 rpm | Output Torque (max eff.): 29 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0144-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/144, 41 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/144 | Output Speed (max eff.): 41 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0212-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/212, 28 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/212 | Output Speed (max eff.): 28 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0263-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/263, 22 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/263 | Output Speed (max eff.): 22 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0294-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/294, 20 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/294 | Output Speed (max eff.): 20 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0504-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/504, 11.7 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/504 | Output Speed (max eff.): 11.7 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0624-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/624, 9.4 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/624 | Output Speed (max eff.): 9.4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0720-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/720, 8.2 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/720 | Output Speed (max eff.): 8.2 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0864-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/864, 6.8 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/864 | Output Speed (max eff.): 6.8 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-1062-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/1062, 5.5 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/1062 | Output Speed (max eff.): 5.5 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-1470-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/1470, 4 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/1470 | Output Speed (max eff.): 4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-2500-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/2500, 2.35 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/2500 | Output Speed (max eff.): 2.35 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-3000-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/3000, 1.96 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/3000 | Output Speed (max eff.): 1.96 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-3600-KD4266T1 GGM K42-4266 DC 12V planetary geared motor, ratio 1/3600, 1.63 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T1 | Voltage: DC 12V | Gear Ratio: 1/3600 | Output Speed (max eff.): 1.63 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 3.8 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-0004-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/4, 1470 rpm / 1.7 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/4 | Output Speed (max eff.): 1470 rpm | Output Torque (max eff.): 1.7 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 32.5 mm | Type: DC planetary geared motor
K42-0014-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/14, 420 rpm / 4.9 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 420 rpm | Output Torque (max eff.): 4.9 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: DC planetary geared motor
K42-0017-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/17, 346 rpm / 5.9 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/17 | Output Speed (max eff.): 346 rpm | Output Torque (max eff.): 5.9 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: DC planetary geared motor
K42-0024-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/24, 245 rpm / 8.4 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/24 | Output Speed (max eff.): 245 rpm | Output Torque (max eff.): 8.4 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 39.2 mm | Type: DC planetary geared motor
K42-0049-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/49, 120 rpm / 14 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/49 | Output Speed (max eff.): 120 rpm | Output Torque (max eff.): 14 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0061-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/61, 96 rpm / 17 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/61 | Output Speed (max eff.): 96 rpm | Output Torque (max eff.): 17 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0084-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/84, 70 rpm / 24 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/84 | Output Speed (max eff.): 70 rpm | Output Torque (max eff.): 24 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0104-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/104, 57 rpm / 29 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/104 | Output Speed (max eff.): 57 rpm | Output Torque (max eff.): 29 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0144-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/144, 41 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/144 | Output Speed (max eff.): 41 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 45.9 mm | Type: DC planetary geared motor
K42-0212-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/212, 28 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/212 | Output Speed (max eff.): 28 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0263-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/263, 22 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/263 | Output Speed (max eff.): 22 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0294-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/294, 20 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/294 | Output Speed (max eff.): 20 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0504-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/504, 11.7 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/504 | Output Speed (max eff.): 11.7 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0624-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/624, 9.4 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/624 | Output Speed (max eff.): 9.4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0720-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/720, 8.2 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/720 | Output Speed (max eff.): 8.2 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-0864-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/864, 6.8 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/864 | Output Speed (max eff.): 6.8 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 52.6 mm | Type: DC planetary geared motor
K42-1062-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/1062, 5.5 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/1062 | Output Speed (max eff.): 5.5 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-1470-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/1470, 4 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/1470 | Output Speed (max eff.): 4 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-2500-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/2500, 2.35 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/2500 | Output Speed (max eff.): 2.35 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-3000-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/3000, 1.96 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/3000 | Output Speed (max eff.): 1.96 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
K42-3600-KD4266T2 GGM K42-4266 DC 24V planetary geared motor, ratio 1/3600, 1.63 rpm / 30 kgf·cm @ max eff. GGM Motor: KD4266T2 | Voltage: DC 24V | Gear Ratio: 1/3600 | Output Speed (max eff.): 1.63 rpm | Output Torque (max eff.): 30 kgf·cm | No-load Speed: 7000 rpm | Stall Torque: 4.3 kgf·cm | Frame: ø42mm | Output Shaft: ø8mm, 4-M4 flange (PCD ø35) | Gearhead Length L: 59.3 mm | Type: DC planetary geared motor
