[GGM] — KD3448-E Series DC Motor with Encoder (ø34mm, 12/24V)
Family ID: GGM-KD3448-E
GGM KD3448 brushed DC motor, ø34mm can, ø3mm shaft, 2-M3 face mount; S/T/P speed grades (12V/24V); body 70.5mm, 140g. Built-in 20-pole/10-pulse incremental encoder, 6-pin connector (open-collector, Vcc DC 5-24V).
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KD3448S1-E | GGM KD3448S1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 5200 rpm, max-eff 4500 rpm / 80 gf·cm. | GGM | Model: KD3448S1-E | Voltage: DC 12V | No-load Speed: 5200 rpm | Rated Speed (max eff.): 4500 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 0.5 A | Stall Torque: 830 gf·cm | Stall Current: 3.2 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder | ||
| KD3448S2-E | GGM KD3448S2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 5200 rpm, max-eff 4500 rpm / 80 gf·cm. | GGM | Model: KD3448S2-E | Voltage: DC 24V | No-load Speed: 5200 rpm | Rated Speed (max eff.): 4500 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 0.3 A | Stall Torque: 790 gf·cm | Stall Current: 2 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder | ||
| KD3448T1-E | GGM KD3448T1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 7500 rpm, max-eff 6500 rpm / 80 gf·cm. | GGM | Model: KD3448T1-E | Voltage: DC 12V | No-load Speed: 7500 rpm | Rated Speed (max eff.): 6500 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 0.7 A | Stall Torque: 730 gf·cm | Stall Current: 5 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder | ||
| KD3448T2-E | GGM KD3448T2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 7500 rpm, max-eff 6500 rpm / 80 gf·cm. | GGM | Model: KD3448T2-E | Voltage: DC 24V | No-load Speed: 7500 rpm | Rated Speed (max eff.): 6500 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 0.4 A | Stall Torque: 700 gf·cm | Stall Current: 3 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder | ||
| KD3448P1-E | GGM KD3448P1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 9000 rpm, max-eff 8000 rpm / 80 gf·cm. | GGM | Model: KD3448P1-E | Voltage: DC 12V | No-load Speed: 9000 rpm | Rated Speed (max eff.): 8000 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 0.8 A | Stall Torque: 670 gf·cm | Stall Current: 5.5 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder | ||
| KD3448P2-E | GGM KD3448P2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 9000 rpm, max-eff 8000 rpm / 80 gf·cm. | GGM | Model: KD3448P2-E | Voltage: DC 24V | No-load Speed: 9000 rpm | Rated Speed (max eff.): 8000 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 0.5 A | Stall Torque: 750 gf·cm | Stall Current: 3.5 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder |
