[GGM] — KGV-3657-U1 Geared DC Motor (DC 12V, 6000rpm base, 4 ratios 1/60-1/120)
Family ID: GGM-KGV3657-U1
GGM KGV-3657-U1 geared DC motor, DC 12V (6000 rpm base motor). 4 gear ratios 1/60-1/120, output torque up to 13.9 kgf·cm, ø8 output shaft, 6-M4 mounting. Output shaft rotates CW with motor (+) to (+). Stall 10 A / 1.6 kgf·cm.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGV-0060-KD3657U1 | KGV-3657-U1 geared, 1/60, 83rpm, 6.9kgf·cm | GGM | Gear Ratio: 1/60 | Output Speed: 83 rpm | Output Torque: 6.9 kgf·cm | ||
| KGV-0090-KD3657U1 | KGV-3657-U1 geared, 1/90, 55rpm, 10.4kgf·cm | GGM | Gear Ratio: 1/90 | Output Speed: 55 rpm | Output Torque: 10.4 kgf·cm | ||
| KGV-0105-KD3657U1 | KGV-3657-U1 geared, 1/105, 47rpm, 12kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 47 rpm | Output Torque: 12 kgf·cm | ||
| KGV-0120-KD3657U1 | KGV-3657-U1 geared, 1/120, 41rpm, 13.9kgf·cm | GGM | Gear Ratio: 1/120 | Output Speed: 41 rpm | Output Torque: 13.9 kgf·cm |
