Chains & Wires
KBC
[KBC] — 560-1512 Forged Shackle Single
Family ID: 560-1512
KBC Forged Shackle Single is a heavy-duty connecting hardware component sourced direct from Korea. Forged shackles of this type are widely used in rigging, lifting, and load-securing applications across construction, marine, and industrial environments where reliable pin connections are essential. Request a quote today for export-ready supply at competitive pricing through a KITA-registered Korean exporter.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 560-1512 | — | KBC | 13mm (1/2') | Spec: 13 | Weight: 0.5 | L: 124 | Safe Working Load: 1.0 | A: 37 | d: 13 | B: 38 | B1: 17 | ||
| 560-1521 | — | KBC | 16mm (5/8') | Spec: 16 | Weight: 0.9 | L: 156 | Safe Working Load: 1.5 | A: 42 | d: 16 | B: 46 | B1: 23 | ||
| 560-1530 | — | KBC | 19mm (3/4') | Spec: 19 | Weight: 1.4 | L: 182 | Safe Working Load: 2.5 | A: 46 | d: 19 | B: 48 | B1: 26 | ||
| 560-1549 | — | KBC | 22mm (7/8') | Spec: 22 | Weight: 1.9 | L: 208 | Safe Working Load: 5.0 | A: 47 | d: 22 | B: 53 | B1: 27 | ||
| 560-1558 | — | KBC | 25mm (1') | Spec: 25 | Weight: 2.7 | L: 233 | Safe Working Load: 6.5 | A: 54 | d: 25 | B: 62 | B1: 30 | ||
| 560-1567 | — | KBC | 29mm (1 1/8') | Spec: 28 | Weight: 4.1 | L: 250 | Safe Working Load: 8.0 | A: 57 | d: 28 | B: 63 | B1: 37 | ||
| 560-1576 | — | KBC | 32mm (1 1/4') | Spec: 32 | Weight: 5.6 | L: 276 | Safe Working Load: 10.0 | A: 64 | d: 32 | B: 66 | B1: 37 | ||
| 560-1585 | — | KBC | 38mm (1 1/2') | Spec: 38 | Weight: 8.2 | L: 328 | Safe Working Load: 15.0 | A: 69 | d: 38 | B: 82 | B1: 46 |
