![[KBC] — 560-1594 Forged Shackle Double](https://img.prosourcemro.com/2026/05/3349329-1-2.jpg)
Chains & Wires
KBC
[KBC] — 560-1594 Forged Shackle Double
Family ID: 560-1594
KBC Forged Shackle Double is a heavy-duty connecting hardware component sourced direct from Korea. Forged shackles of this type are widely used in rigging, lifting, and load-securing applications across construction, marine, and industrial environments where reliable connection points are essential. Request a quote today for export-ready supply at competitive pricing through a KITA-registered Korean exporter.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 560-1594 | — | KBC | 13mm (1/2') | Spec: 13 | Weight: 0.7 | L: 158 | Safe Working Load: 1.0 | d: 13 | B: 37 | B1: 37 | ||
| 560-1600 | — | KBC | 16mm (5/8') | Spec: 16 | Weight: 1.2 | L: 196 | Safe Working Load: 1.5 | d: 16 | B: 46 | B1: 46 | ||
| 560-1619 | — | KBC | 19mm (3/4') | Spec: 19 | Weight: 2.1 | L: 222 | Safe Working Load: 2.5 | d: 19 | B: 63 | B1: 50 | ||
| 560-1628 | — | KBC | 22mm (7/8') | Spec: 22 | Weight: 2.6 | L: 258 | Safe Working Load: 5.0 | d: 22 | B: 75 | B1: 53 | ||
| 560-1637 | — | KBC | 25mm (1') | Spec: 25 | Weight: 4.0 | L: 284 | Safe Working Load: 6.5 | d: 25 | B: 85 | B1: 62 | ||
| 560-1646 | — | KBC | 29mm (1 1/8') | Spec: 28 | Weight: 5.9 | L: 300 | Safe Working Load: 8.0 | d: 28 | B: 86 | B1: 63 | ||
| 560-1655 | — | KBC | 32mm (1 1/4') | Spec: 32 | Weight: 7.8 | L: 336 | Safe Working Load: 10.0 | d: 32 | B: 98 | B1: 76 | ||
| 560-1664 | — | KBC | 38mm (1 1/2') | Spec: 38 | Weight: 10.6 | L: 410 | Safe Working Load: 15.0 | d: 38 | B: 116 | B1: 90 |
