Sensorless Servo Geared Motors
MITSUBISHI ELECTRIC
[MITSUBISHI ELECTRIC] — GV-S 0.4kW S-PM Sensorless Servo Geared Motor (Leg Mount)
Family ID: MEL-GV-S-04-LEG
Mitsubishi Electric GV-S 0.4kW S-PM sensorless servo geared motor, leg mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range. Nominal reduction ratios 1/5 to 1/900 with permissible output torque 5.7 to 769 Nm. Motor rated 3000 r/min, 4P, insulation class 130(B), grease-lubricated, IP44 indoor. Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power).
20 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| GV-S 0.4kW 1/5 | GV-S 0.4kW 1/5, leg mount, 5.7Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/5 · Actual Ratio: 1/4.97 · Output Speed: 600 r/min (motor 3000 r/min) · Permissible Output Torque: 5.7 Nm · Permissible Overhang Load: 685 N · Permissible Thrust Load: 25 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/10 | GV-S 0.4kW 1/10, leg mount, 11Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/10 · Actual Ratio: 1/9.93 · Output Speed: 300 r/min (motor 3000 r/min) · Permissible Output Torque: 11 Nm · Permissible Overhang Load: 685 N · Permissible Thrust Load: 42 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/15 | GV-S 0.4kW 1/15, leg mount, 17Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/15 · Actual Ratio: 1/14.81 · Output Speed: 200 r/min (motor 3000 r/min) · Permissible Output Torque: 17 Nm · Permissible Overhang Load: 685 N · Permissible Thrust Load: 42 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/20 | GV-S 0.4kW 1/20, leg mount, 23Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/20 · Actual Ratio: 1/20.08 · Output Speed: 150 r/min (motor 3000 r/min) · Permissible Output Torque: 23 Nm · Permissible Overhang Load: 685 N · Permissible Thrust Load: 83 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/25 | GV-S 0.4kW 1/25, leg mount, 27Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/25 · Actual Ratio: 1/23.85 · Output Speed: 120 r/min (motor 3000 r/min) · Permissible Output Torque: 27 Nm · Permissible Overhang Load: 685 N · Permissible Thrust Load: 83 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/30 | GV-S 0.4kW 1/30, leg mount, 33Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/30 · Actual Ratio: 1/28.88 · Output Speed: 100 r/min (motor 3000 r/min) · Permissible Output Torque: 33 Nm · Permissible Overhang Load: 880 N · Permissible Thrust Load: 125 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/40 | GV-S 0.4kW 1/40, leg mount, 44Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/40 · Actual Ratio: 1/41.07 · Output Speed: 75 r/min (motor 3000 r/min) · Permissible Output Torque: 44 Nm · Permissible Overhang Load: 1180 N · Permissible Thrust Load: 167 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/50 | GV-S 0.4kW 1/50, leg mount, 53Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/50 · Actual Ratio: 1/48.96 · Output Speed: 60 r/min (motor 3000 r/min) · Permissible Output Torque: 53 Nm · Permissible Overhang Load: 1180 N · Permissible Thrust Load: 208 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/60 | GV-S 0.4kW 1/60, leg mount, 66Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/60 · Actual Ratio: 1/60.54 · Output Speed: 50 r/min (motor 3000 r/min) · Permissible Output Torque: 66 Nm · Permissible Overhang Load: 1230 N · Permissible Thrust Load: 250 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/80 | GV-S 0.4kW 1/80, leg mount, 87Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/80 · Actual Ratio: 1/80.50 · Output Speed: 37.5 r/min (motor 3000 r/min) · Permissible Output Torque: 87 Nm · Permissible Overhang Load: 1570 N · Permissible Thrust Load: 300 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/100 | GV-S 0.4kW 1/100, leg mount, 97Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/100 · Actual Ratio: 1/89.57 · Output Speed: 30 r/min (motor 3000 r/min) · Permissible Output Torque: 97 Nm · Permissible Overhang Load: 1620 N · Permissible Thrust Load: 300 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/120 | GV-S 0.4kW 1/120, leg mount, 122Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/120 · Actual Ratio: 1/112.29 · Output Speed: 25 r/min (motor 3000 r/min) · Permissible Output Torque: 122 Nm · Permissible Overhang Load: 2350 N · Permissible Thrust Load: 500 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/160 | GV-S 0.4kW 1/160, leg mount, 160Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/160 · Actual Ratio: 1/148.08 · Output Speed: 18.8 r/min (motor 3000 r/min) · Permissible Output Torque: 160 Nm · Permissible Overhang Load: 2350 N · Permissible Thrust Load: 500 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/200 | GV-S 0.4kW 1/200, leg mount, 198Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/200 · Actual Ratio: 1/182.78 · Output Speed: 15 r/min (motor 3000 r/min) · Permissible Output Torque: 198 Nm · Permissible Overhang Load: 2350 N · Permissible Thrust Load: 500 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/270 | GV-S 0.4kW 1/270, leg mount, 256Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/270 · Actual Ratio: 1/251.20 · Output Speed: 11.1 r/min (motor 3000 r/min) · Permissible Output Torque: 256 Nm · Permissible Overhang Load: 2650 N · Permissible Thrust Load: 500 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/360 | GV-S 0.4kW 1/360, leg mount, 349Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/360 · Actual Ratio: 1/342.55 · Output Speed: 8.3 r/min (motor 3000 r/min) · Permissible Output Torque: 349 Nm · Permissible Overhang Load: 2700 N · Permissible Thrust Load: 500 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/450 | GV-S 0.4kW 1/450, leg mount, 436Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/450 · Actual Ratio: 1/427.98 · Output Speed: 6.7 r/min (motor 3000 r/min) · Permissible Output Torque: 436 Nm · Permissible Overhang Load: 2740 N · Permissible Thrust Load: 500 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/540 | GV-S 0.4kW 1/540, leg mount, 519Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/540 · Actual Ratio: 1/509.38 · Output Speed: 5.6 r/min (motor 3000 r/min) · Permissible Output Torque: 519 Nm · Permissible Overhang Load: 3920 N · Permissible Thrust Load: 700 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/720 | GV-S 0.4kW 1/720, leg mount, 722Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/720 · Actual Ratio: 1/708.40 · Output Speed: 4.2 r/min (motor 3000 r/min) · Permissible Output Torque: 722 Nm · Permissible Overhang Load: 3920 N · Permissible Thrust Load: 700 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order | ||
| GV-S 0.4kW 1/900 | GV-S 0.4kW 1/900, leg mount, 769Nm, no brake | MITSUBISHI ELECTRIC | Series: GV-S (S-PM sensorless servo) · Type: Parallel Shaft · Mount: Leg mount · Brake: None · Output: 0.4kW · Poles: 4P · Nominal Ratio: 1/900 · Actual Ratio: 1/787.10 · Output Speed: 3.3 r/min (motor 3000 r/min) · Permissible Output Torque: 769 Nm (torque-limited) · Permissible Overhang Load: 3920 N · Permissible Thrust Load: 700 N · Motor Rated Voltage: 175V · Motor Rated Current: 1.6A · Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) · Insulation: 130(B) · Enclosure: Totally-enclosed non-ventilated (TENV) · Lubrication: Grease · Protection: IP44 (indoor) · Availability: Made-to-order |
